Crestron DM-RMC-SCALER-C User Manual

DigitalMedia 8G+ Receiver Crestron DM-RMC-SCALER-C
22
•
DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B
IP Configuration
If the DM-RMC-SCALER-C is used in a standalone configuration (without a DM
switcher), use Crestron Toolbox to create the IP table entry of the
DM-RMC-SCALER-C.
NOTE: If the DM-RMC-SCALER-C is connected to a DM switcher, the IP table
entry of the DM-RMC-SCALER-C is created automatically.
1. Use the Device Discovery Tool to find the IP address of the
DM-RMC-SCALER-C. Then, display the “System Info” window
(Tools | System Info) and select the DM-RMC-SCALER-C entry from the
Address Book.
2. Select Functions | IP Table Setup.
3. Add, modify, or delete entries in the IP table. The DM-RMC-SCALER-C
can have only one IP table entry.
4. A defined IP table can be saved to a file or sent to the device.

Crestron DM-RMC-SCALER-C Specifications

General

Product color	Black
Heat dissipation	41 BTU/h
Housing material	Metal
Scaled resolutions	640 x 480, 800 x 600, 848 x 480, 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 768, 1280 x 800, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1600 x 900, 1680 x 1050, 1920 x 1080, 1920 x 1200
RJ-45 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC adapter frequency	50/60 Hz
AC adapter input current	0.75 A
AC adapter input voltage	100-240 V

Weight and Dimensions

Depth	37 mm
Width	194 mm
Weight	870 g
