Crestron DM-RMC-SCALER-C User Manual

Crestron DM-RMC-SCALER-C DigitalMedia 8G+ Receiver
Operations & Installation Guide – DOC. 7231B DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C
•
1
• DigitalMedia 8G+™ receiver, high-definition scaler, and display
controller
• DM 8G+ input supports up to 330 foot (100 meter) cable length
1
• Connects to a DM
®
switcher or transmitter (each sold separately) over
one CAT5e or Crestron DM 8G cable
1
• HDBaseT certified, which enables direct connection to a third-party
HDBaseT source
• Provides one HDMI or DVI display output
2
• Includes built-in high-definition video scaler
• Accepts any video source from standard NTSC 480i or PAL 576i to
HD 1080p60 with Deep Color
• Also accepts any computer source from VGA to UXGA/WUXGA
• Scales the source to match the native resolution of virtually any popular
video display or computer monitor
• Provides intelligent frame rate conversion
DigitalMedia 8G+ Receiver &
Room Controller with Scaler:
DM-RMC-SCALER-C
Introduction
The DM-RMC-SCALER-C provides an advanced 1-box interface solution for a
single display device as part of a complete Crestron
®
DigitalMedia™ system.
It functions as a DM 8G+™ receiver, video scaler, and control interface, providing a
single HDMI
®
output along with Ethernet, USB HID, RS-232, and IR control ports.
In addition to DM 8G+, it is also compatible with HDBaseT
®
specifications,
allowing it to be connected directly to any HDBaseT compliant source.
Built-in
scaling enables the connected display to handle virtually any video signal up to HD
1080p and WUXGA resolutions. Its compact, low-profile design allows the
DM-RMC-SCALER-C to be installed discreetly behind a flat panel display or above
a ceiling mounted projector. It connects to the head end or source location using a
single CAT5e or Crestron DM 8G
®
cable.
1
Features and Functions
(Continued on following page)
1. For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G™ cable, Crestron
DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or
better) UTP or STP. Maximum wire length for DM 8G+ is 330 feet (100 meters) between devices.
Shielded cable and connectors are recommended to safeguard against unpredictable environmental
electrical noise which may impact performance at resolutions above 1080p. For complete system
design guidelines, refer to the Crestron DigitalMedia Design Guide (Doc. 4546) at
www.crestron.com/dmresources
. DM 8G+ is compatible with HDBaseT Alliance specifications for
connecting to HDBaseT compliant equipment. All wire and cables sold separately.
2. The HDMI output requires an appropriate adapter or interface cable to accommodate a DVI signal.
CBL-HD-DVI interface cables sold separately.

Crestron DM-RMC-SCALER-C Specifications

General

Product color	Black
Heat dissipation	41 BTU/h
Housing material	Metal
Scaled resolutions	640 x 480, 800 x 600, 848 x 480, 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 768, 1280 x 800, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1600 x 900, 1680 x 1050, 1920 x 1080, 1920 x 1200
RJ-45 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC adapter frequency	50/60 Hz
AC adapter input current	0.75 A
AC adapter input voltage	100-240 V

Weight and Dimensions

Depth	37 mm
Width	194 mm
Weight	870 g
