Crestron DM-RMC-SCALER-C User Manual

DigitalMedia 8G+ Receiver Crestron DM-RMC-SCALER-C
2
•
DigitalMedia 8G+ Receiver: DM-RMC-SCALER-C Operations & Installation Guide – DOC. 7231B
• Allows motion-adaptive de-interlacing or interlacing
• Allows adjustable overscan or underscan up to 7.5%
• Provides automatic 3D-to-2D signal conversion
1
• Automatically passes 3D video without scaling to 3D capable displays
1
• Includes content-adaptive noise reduction
• 100% HDCP compliant
• Scalable zoom feature enables 2 x 2, 3 x 2, 3 x 3, 4 x 3, or 4 x 4 video
wall capability
2
• Handles Dolby
®
TrueHD, DTS-HD Master Audio™, and uncompressed
7.1 linear PCM audio
• Provides 10BASE-T/100BASE-TX Ethernet and USB HID mouse and
keyboard ports
• Compatible with Crestron USB Extenders to enable expanded USB
device support
3
• Enables device control via CEC, IR, RS-232, and Ethernet
• Allows quick, easy setup and diagnostics
• Low-profile design mounts to a 2-gang US, UK, or European
electrical box
Features and Functions
(Continued)
DigitalMedia 8G+
DigitalMedia 8G+ provides a true 1-wire transport for moving high-definition video,
audio, and Ethernet over low-cost twisted pair cable without compression or
repeaters. Engineered for ultra high bandwidth and ultimate scalability, DM 8G+
handles uncompressed video beyond high definition with support for HDCP, Deep
Color, and 3D. Audio capabilities include support for high-bitrate 7.1 audio formats
like Dolby TrueHD and DTS-HD Master Audio
as well as uncompressed linear
PCM. All signals are transported over one 8-conductor twisted pair cable, supporting
distances up to 330 feet (100 meters) using Crestron DM 8G cable or CAT5e.
4
HDBaseT Certified
Crestron DigitalMedia 8G+ technology is designed using HDBaseT Alliance
specifications, ensuring interoperability with third-party HDBaseT products. Via its
DM 8G+ input, the DM-RMC-SCALER-C can be connected directly to any
HDBaseT compliant source without requiring a DM transmitter. HDBaseT
connectivity through the DM-RMC-SCALER-C converges uncompressed full HD
digital video, audio, Ethernet, and control signals through a single CAT5e or CAT6
cable over distances up to 330 feet (100 meters).
1. Automatically passes 3D video if display device supports it (reverts to pass-through mode
without scaling). Provides automatic 3D-to-2D conversion (with scaling) if display device does not
support 3D.
2. Video wall processing requires a separate DM-RMC-SCALER-C for each individual display.
3. Compatible with Crestron USB-EXT-DM-LOCAL and USB-EXT-DM-REMOTE USB Extenders,
sold separately.
4. For DM 8G+ or HDBaseT wiring, use Crestron DM-CBL-8G DigitalMedia 8G cable, Crestron
DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or third-party CAT5e (or
better) UTP or STP. Maximum wire length for DM 8G+ is 330 feet (100 meters) between devices.
Shielded cable and connectors are recommended to safeguard against unpredictable environmental
electrical noise which may impact performance at resolutions above 1080p. For complete system
design guidelines, refer to the Crestron DigitalMedia Design Guide (Doc. 4546). DM 8G+ is
compatible with HDBaseT Alliance specifications for connecting to HDBaseT compliant equipment.
All wire and cables sold separately.

Crestron DM-RMC-SCALER-C Specifications

General

Product color	Black
Heat dissipation	41 BTU/h
Housing material	Metal
Scaled resolutions	640 x 480, 800 x 600, 848 x 480, 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 768, 1280 x 800, 1360 x 768, 1366 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1600 x 900, 1680 x 1050, 1920 x 1080, 1920 x 1200
RJ-45 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC adapter frequency	50/60 Hz
AC adapter input current	0.75 A
AC adapter input voltage	100-240 V

Weight and Dimensions

Depth	37 mm
Width	194 mm
Weight	870 g
