Crestron DM-TX-201-C DigitalMedia 8G+™ Transmitter 201
DM-TX-201-C Specifications (Continued)
SPECIFICATION DETAILS
Audio (Continued)
Performance (Analog)
Frequency Response 20 Hz to 20 kHz ±0.75 dB
S/N Ratio >90 dB, 20 Hz to 20 kHz A-weighted
THD+N <0.05% @ 1 kHz
Stereo Separation >90 dB
Communications
DigitalMedia
DM 8G+, HDCP management, EDID format
management, CEC
Ethernet
10BASE-T/100BASE-TX, auto-switching,
auto-negotiating, auto-discovery, full/half
duplex, TCP/IP, UDP/IP, CIP, DHCP, RSTP
USB Supports USB HID class devices
Power Requirements
4
Power Pack
0.75 Amps @ 24 Volts DC;
100-240 Volts AC, 50/60 Hz power pack
included
Power over DM
Receives power from a DM 8G+ power
sourcing device
Minimum 2-Series Control
System Update File
5, 6
Version 4.001.1012 or later
Environmental
Temperature 32º to 104º F (0º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 30 BTU/Hr
Enclosure
Chassis
Metal, black finish, with two integral
mounting flanges, vented sides
Mounting
Freestanding, surface mount, or attach to a
single rack rail
Dimensions
Height 6.47 in (165 mm)
Width 7.36 in (187 mm)
Depth 1.24 in (32 mm)
Weight 26 oz (721 g)
Included Accessory 24 Volt DC Power Pack
Available Accessories
CBL-AUDIO
Crestron Certified Mini-TRS Stereo Audio
Interface Cable
CBL-HD Crestron Certified HDMI Interface Cable
CBL-HD-DVI
Crestron Certified HDMI to DVI Interface
Cable
CBL-VGA
Crestron Certified Computer VGA Interface
Cable
(Continued on following page)
Operations & Installation Guide – DOC. 6958B DigitalMedia 8G+™ Transmitter 201: DM-TX-201-C • 7

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
