16
•
HD-MD-6X2/4X2/4X1-4K-E: 4K HDMI Switchers Supplemental Guide – DOC. 7761A
Laptop widescreen 2CH
Consumer 4k 25Hz HBR 3D
Consumer 4k 30Hz HBR 3D
Consumer 1080P50 3D HBR
Consumer 1080P50 HBR
Consumer 1080P 3D HBR
Consumer 1080P HBR
Consumer 720P50 HBR
Consumer 720P HBR
External EDID 1
External EDID 2
External EDID 3
External EDID 4
External EDID 5
External EDID 6
External EDID 7
External EDID 8
Copy Output 1
Copy Output 2 (applicable to the HD-MD6X2-4K-E and
HD-MD4X2-4K-E only)
NOTE:
In the list above,
External EDID 1
through
External
EDID 8
represent placeholders for custom-loaded EDID files.
NOTE:
Selecting
Output 1
or
Output 2
copies the EDID from the
output to all of the inputs.
ii. Select the desired EDID.
A prompt appears asking for confirmation that the selected EDID
be applied to all inputs.
iii. Select
Yes
or
No:
• If
Yes
is selected, the
Setting…
message appears, and
then the OLED display returns to the Inputs submenu.
• If
No
is selected, the OLED display returns to the list of
available EDIDs.
b. Configure each input on an individual basis by selecting the input number
in the Inputs submenu.
The Input Status and Configuration submenu opens for the selected input.
Input Status and Configuration Submenu (Input 1 Shown)
< Input 1 >
Status
