Crestron AV3 & PRO3 3-Series Control Systems
Operations Guide – DOC. 7330C 3-Series Control Systems: AV3 & PRO3
13
Setup
Network Wiring
When wiring the Cresnet network, consider the following:
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results or damage
to the equipment. Use the Crestron Power Calculator to help calculate how
much power is needed for the system (
www.crestron.com/calculators).
For Cresnet networks with 20 or more devices, use a Cresnet Hub/Repeater
(CNXHUB) to maintain signal quality.
For more details, refer to “Check Network Wiring” which starts on page 44.
The AV3 and PRO3 can also use high-speed Ethernet on a dedicated Control Subnet
for communications between the control system and Crestron Ethernet devices.
For general information on connecting Ethernet devices in a Crestron system, refer to
the latest version of the Crestron e-Control Reference Guide (Doc. 6052), which is
available from the Crestron Web site (www.crestron.com/manuals
).
Identity Code
NOTE: The latest software can be downloaded from the Crestron Web site
(www.crestron.com/software).
Net ID
The Net ID of the AV3 and PRO3 has been factory set to 02. This Net ID is defined
as the “Master” control system on the Cresnet network and cannot be changed.
IP ID
The IP ID is set within the AV3 or PRO3’s IP table using Crestron Toolbox. For
information on setting an IP table, refer to the Crestron Toolbox help file.
NOTE: The IP ID for multiple AV3s or PRO3s should be the same if the AV3s or
PRO3s need to communicate with each other.
When setting the IP ID, consider the following:
• The IP ID of each unit must match an IP ID specified in the Crestron Studio
or SIMPL Windows program.
• Each device using IP to communicate with a control system must have a
unique IP ID.
