Crestron UC-2 - Hardware Setup; Power and Network Connectivity

UC-2 Quick Start
Hardware Hookup
Make connections as shown in the following diagram.
If using the included power supply to provide PoE to the UC-2, connect the supply as
shown below.
Connec
t a laptop computer with the included USB cable to the USB port and use the
laptop’s UC software for a conference call.
Laptop
Power over Ethernet
(PoE)
UC-2 LAN port
Power
supply
LAN
DATA
