Pinto BT-POM 1212 - Revision 5
7.1
Section 7
Assembly Drawings & Parts Listings
AR135 Pump 7.2
AR160/185 Pump 7.4
AR250/280 Pump 7.6
Liquid Control System 7.8
Pinto Panel Assembly Autorate 7.9
Servo/Dump/Flowmeter 7.10
Valves & Enviro-Transfer Kit 7.11
Chem E Flush Assembly 7.12
Filters 7.14
Lids, Venturis & Tank Rinse Jet 7.15
Foam Marker 20LPM 7.16
Foam Marker Components 7.17
Boom Fittings 7.18
Nozzles & Nozzle Bodies 7.19
Tank & Chassis 7.20
Wheel Hubs 7.22
Plumbing Diagram AR60/AR135 7.25
Electrical Diagrams 7.26
Hydraulic Plumbing Diagrams 7.30
Booms 7.38
