7.3
Pinto BT-POM 1212 - Revision 5
Section 7
58 AR580072 Left Hand Manifold Coupling 1
59 AR1500350 Cardan Protection 1
60 AR550332 Washer 2
61 AR320621 Washer 5
62 AR740290 O-Ring 1
63 AR580330 C - Shaft 1
64 AR580370 Plate 3
65 AR580360 Diaphragm pin 3
66 AR250310 O-Ring 1
67 AR580080 Base 1
68 AR540301 Bolt 1
69 AR200233 Washer 2
70 AR580400 Right manifold coupling + outlet 1
71 AR550460 Elbow 1
72 AR550450 Ring nut 1
73 AR880831 O-Ring 1
74 AR1609000 Safety Valve 1
75 AR881560 Elbow 1
76 AR580421 Extension 1
78 AR850851 Bolt 2
79 AR620472 Bolt 2
80 AR580430 CR x S Shaft 1
81 AR390180 O-Ring 2
82 AR1040310 Oil Tank 1
83 AR650920 O-Ring 1
84 AR1040320 Red Oil Tank Cap 1
85 AR620561 O-Ring 1
86 AR621440 Spigot 1
87 AR580230 O-Ring 1
88 AR550920 Flange 1
89 AR550950 Bolt 3
90 AR550940 Gear 1
91 AR620301 Plug 3
92 AR160671 Bolt 4
93 AR621810 Bolt 1
94 AR621820 Pinion 1
95 AR480820 Seal 1
96 AR881090 Key 1
97 AR651000 Bolt 3
98 AR800800 Bolt 1
99 AR540290 Bolt 4
Pos Part No Description Qty
AR135 Pump
Pos Part No Description Qty
1 AR580011 Pump Body 1
2 AR580150 Manifold Line 1
3 AR550101 Right Head 2
4 AR550102 Left Head 1
5 AR180152 Nut 15
8 AR550080 Diaphragm - Gomma (Use AR550086) 3
AR550084 Diaphragm - Viton 3
AR550085 Diaphragm - Desmopan 3
AR550086 Diaphragm - HPDS 3
9 AR580350 Sleeve 3
10 AR500260 Piston RIng 3
12 AR580120 Piston 3
13 AR380300 Pin 3
14 AR380080 Pin Ring 6
15 AR580140 Connecting Rod 3
16 AR320030 O-Ring 6
17 AR759051 Complete Valve 6
18 AR540541 Ring Nut 1
19 AR390291 O-Ring 7
20 AR540530 Threaded Adapter 1
21 AR390271 Nut 3
23 AR580050 Gasket 1
25 AR580180 Lower Air Chamber 1
26 AR550190 Semi Air Chamber 1
AR550191 Semi Air Chamber 1
AR550192 Semi Air Chamber 1
27 AR550233 Upper Air Chamber 1
28 AR550300 Air Valve 1
29 AR650542 Gasket 1
30 AR550680 Bolt 4
31 AR200391 Circlip 1
32 AR550470 Gasket Retainer 1
33 AR550070 Spacer Ring 1
34 AR580440 Roller Bushing 1
35 AR580380 ‘SP’ Shaft 1
36 AR580130 Conrod Ring (Use AR580470) 2
37 AR550200 Stud 4
38 AR550310 Roller Bushing 1
46 AR550340 Threaded Adapter 1
47 AR550350 O-Ring 1
48 AR550242 Ring Nut 1
49 AR550370 Elbow 1
50 AR540550 Elbow 1
52 AR250310 O-Ring 1
53 AR550491 Seal Ring 1
54 AR650920 O-Ring 1
55 AR880530 Plug 1
57 AR580071 Right Hand Manifold Coupling 1
Parts in italics are non-stock items and may need to be ordered.
NOTE
