7.5
Pinto BT-POM 1212 - Revision 5
Section 7 AR160/185 Pump
1 AR3040430 Ø 40 Elbow - AR 160 bp 1
AR3040440 Ø 50 Elbow - AR 185 bp 1
2 AR3040450 2” G Ring nut 1
5 AR3040470 OR Ø 39.3 x 2.6 O-ring 2
6 AR760750 Line 1
7 AR380242 M8 Nut - Geomet C 20 18
AR380244 M8 Nut - Inox C 20 18
8 AR751350 Head 4
AR751352 Head 4
9 AR680070 OR Ø 31.5 x 4.25 O-ring 8
10 AR759051 Valve 8
11 AR750071 TE M12 x 70 Screw - Geomet C 50 4
AR750072 TE M12 x 70 Screw 4
12 AR880530 3/8” G Plug - C 20 2
AR2340350 3/8” G Plug - Inox C 20 2
13 AR750110 Sleeve - AR 160 bp 4
AR750115 Sleeve - AR 185 bp 4
14 AR750061 TE M12 x 65 Screw - Geomet C 50 12
AR750062 TE M12 x 65 Screw - Inox C 50 12
15 AR680350 TCEI M8 x 35 Screw 2
16 AR1040060 Ø 72.69 x 2.62 O-ring 1
17 AR750057 Plug - AR 160 bp 1
AR750052 Plug - AR 185 bp 1
18 AR750030 Tank 1
19 AR750040 Gasket 1
20 AR761010 Pump body 1
21 AR851360 Ø 120.32 x 2.62 O-ring 1
22 AR680020 Support 1
23 AR160672 TE M10 x 25 Screw - Geomet C 40 6
AR160673 TE M10 x 25 Screw - Inox C 40 6
24 AR751130 1”1/2 G M-M Fitting 1
25 AR390290 Ø 29x3 O-ring 1
26 AR750670 1” 1/2 G Ring nut 1
27 AR760930 Ø 25 Elbow - AR 160 bp 1
AR3040160 Ø 35 Elbow - AR 185 bp 1
28 AR2420181 Support 1
29 AR650640 TCEI M10 x 25 Screw - Geomet C 40 6
AR650642 TCEI M10 x 25 Screw - Inox C 40 6
30 AR550080 Diaphragm - NBR 4
AR550084 Diaphragm - Viton 4
AR550085 Diaphragm - Desmopan 4
AR550086 Diaphragm - HPDS 4
32 AR500260 Piston ring 4
33 AR750122 Ø 80 Piston 4
34 AR760760 Line 1
35 AR160700 Pin 4
36 AR160691 Øi 18 Ring 8
37 AR760140 Connecting-rod 4
38 AR750090 Bearing 2
39 AR750130 Ring 2
40 AR540040 Plate 2
41 AR230350 Bearing 2
42 AR160740 Ring 2
43 AR200390 Øi 62 Ring 2
44 AR760201 Foot 2
45 AR750170 C/C m-AU Shaft - AR 160 bp 1
AR750174 C/C m-AV Shaft - AR 185 bp 1
46 AR390290 Ø 29x3 O-ring 1
47 AR380243 Washer - Geomet 18
AR390315 Washer - Inox 18
48 AR250143 Washer - Geomet 4
AR250144 Washer - Inox 4
50 AR330173 1/2” G Plug - Geomet C 20 1
AR330174 1/2” G Plug - Inox C 20 1
52 AR550190 Semi air chamber - NBR 1
AR550191 Semi air chamber - Saturfl on 1
AR550192 Semi air chamber - Viton 1
AR550193 Semi air chamber - HPDS 1
53 AR650542 Gasket 1
54 AR180020 Air valve 1
55 AR620232 Semi air chamber 1
56 AR621781 TE M8 x 40 Screw 8
62 AR1782 TE M8 x 40 Screw 8
58 AR680180 Halfball 1
59 AR1500470 Cardan protection 2
60 AR850251 M8 x 12 Screw 3
AR850252 TCEI M8 x 12 Screw 3
61 AR180101 Ø 17.5 x 2 O-ring 1
62 AR1552 Air chamber 1
65 AR740290 Ø 14 x 1.78 O-ring 2
67 AR881560 1/2” G M-F Fitting 1
68 AR1609000 Safety valve 1
69 AR880831 Ø 15.54 x 2.62 O-ring - Viton 1
70 AR550450 3/4” G Ring nut 1
71 AR550460 Ø 18 Elbow 1
72 AR390314 Washer - Geomet 3
AR390315 Washer - Inox 3
74 AR751140 Ø 47.22 x 3.53 O-ring 1
78 AR620330 Øi 65 Ring 1
79 AR1800090 Ring 1
80 AR230310 Bearing 1
81 AR760510 Plate 1
82 AR760450 C/F Ø25 m-BX Shaft - AR 160 bp 1
AR760520 C/F Ø32 m-BS Shaft - AR 160 bp 1
AR760460 C/F Ø25 m-BZ Shaft - AR 185 bp 1
AR760530 C/F Ø32 m-BT Shaft - AR 185 bp 1
103 AR2240100 Hub pin 4
104 AR2240110 M10 Nut 4
105 AR751250 Wobble plate 4
106 AR760950 Ø 40 Hose tail - AR 160 bp 1
AR760570 Ø 50 Hose tail - AR 1854 bp 1
110 AR760920 Ø 25 Hose tail - AR 160 bp 1
AR760940 Ø 35 Hose tail - AR 185 bp 1
111 AR820673 TCEI M10 x 16 Screw - Geomet 3
AR820672 TCEI M10 x 16 Screw - Inox 3
112 AR320621 Washer 3 Geomet
AR320622 10.5 x 21x 2 Washer - Inox 3
113 AR761030 Foot 2
114 AR160672 TE M10 x 25 Screw - Geomet C 20 6
AR160673 TE M10 x 25 Screw - Inox C 20 6
115 AR1040491 3/8” M-F Fitting 1
116 AR900210 3/8” G M-F Fitting 1
117 AR2260200 Washer 1
118 AR2281270 3/8” G Plug 1
Pos Part No Description Qty Pos Part No Description Qty
Parts in Italics are non-
stocked items and may need
to be ordered.
NOTE
