7.13
Pinto BT-POM 1212 - Revision 5
Section 7
Chem E Flush Assembly
Pos Part No Description Qty Pos Part No Description Qty
L-H9351A 60 litre ChemeFlush
1 A106425 TAIL 1” TO 25MM 1
2 A106640 TAIL 1 1/2” TO 40MM 1
3 A116313 ELBOW D13 FOR FLY NUT 3/4” 1
4 A200030 FLY NUT 3/4” 1
5 A200040 FLY NUT 1” 1
6 A200060 FLY NUT 1 1/2” 1
7 A240045 NIPPLE 1”-1 1/4” REDUCING 1
8 A250030 NIPPLE 3/4” 2
9 A250050 NIPPLE 1 1/4” 1
10 A454135 BALL VALVE POLY 1 1/4” 2 WAY 1
11 A1302050 TEE 1 1/4” 1
12 A2402065 REDUCER NIPPLE 1 1/2”-1 1/4” 2
13 AG4000B FLAT SEAL 5/8” EPDM 1
14 AG10031 O RING 3/4” 1
15 AG10041 O RING 1” 1
16 AG10061 O RING 1 1/2” 1
17 AG40002 FLAT SEAL 1/2” EPDM 1
18 AG40003 FLAT SEAL 3/4” EPDM 2
19 BJHB075 HOSEBARB 3/4” NPT X 3/4” BARB 1
20 BJHB075-050 HOSEBARB 3/4” NPT X 1/2” BARB 1
21 BJHB075-90 ELBOW 3/4” NPT X 3/4” BARB 1
22 BJHB100 HOSEBARB 1”NPT X 1” BARB 2
23 BJSL075-90 ELBOW 3/4” MALE FEMALE 1
24 BJTEE075 TEE 3/4” FEMALE 1
25 BJTEE100 TEE FEMALE THREADED 1” NPT 1
26 BJTF150AV ANTI VORTEX FITTING 1 1/2” 1
27 HPW12 12MM HOSE 1
28 HPW12 12MM HOSE 1
29 HPW12 12MM HOSE 1
30 HPW20 20MM HOSE 1
31 HPW25 25MM HOSE 1
32 KB-1003A-1 60LT CHEM-E-FLUSH MANIFOLD 1
33 P60C-1 60LT CHEMIFLUSH TANK 1
34 P60C-2 LID 1
35 PH4622 ELBOW 3/4” FEMALE 1
36 POL6340839P.CRO RINSING NOZZLE WITH 1/2” TAIL 1
37 POL63402999 LEVER HANDLE CHEM-E--FLUSH 1
38 POL63408499 RINSING NOZZLE 1
39 TR1HC HOSE CLAMP 25MM 1” WORM DRIVE 2
40 TR34HC HOSE CLAMP 20MM 3/4” WORM DRIVE 2
41 TR12HC HOSE CLAMP 20MM 1/2” WORM DRIVE 5
42 UP-105AB CHEM-E-FLUSH MOUNTING BRKT SERIES 2 1
43 UP-116 NOZZLE 8.5 VENTURI CHEM E PLUS 1
44 40SQWASHER 40MM SQUARE WASHER 4
45 .75SSWASHER 3/4” STAINLESS STEEL WASHER 1
46 M6X16 M6 X 16 BOLT HT ZP 2
47 M6NNUT M6 NYLOC NUT 2
48 M6FWASHER M6 FLAT WASHER ZP 4
L-H9355A Drop Down Assembly
1 L-H9355A-1 MAIN FRAME 1
2 L-H9355A-2 HINGE PLATE 2
3 L-H9355A-3 LEVER 1
4 L-H9355A-4 LOCK PLATE 1
5 L-H9355A-5 ARM, INNER 1
6 L-H9355A-6 ARM, OUTER 1
7 L-H9355A-7 LOCK PIN 1
8 L-H9355A-8 BOLTING CHANNEL 1
9 L-H9355A-9 LOCK HANDLE 1
10 L-H9355A-10 STOPPER, TOP 1
11 L-H9355A-11 STOPPER, BOTTOM 1
12 L-H9355A-12 SPRING 4.5 X 210 45 COILS 2
13 L-H9355A-13 SPRING 1.4 X 60 38 COILS 1
14 M16X180 M16 X 180 BOLT HT ZP 2
15 M16X110 M16 X 110 BOLT HT ZP 1
16 M16NNUT M16 NYLOC NUT HT ZP 4
17 M16FWASHER M16 FLAT WASHER ZP 10
18 M14NNUT M14 NYLOC NUT HT ZP 1
19 M12X25 M12 X 25 SET SCREW HT ZP 4
20 M12NNUT M12 NYLOC NUT HT ZP 5
21 M12FWASHER M12 FLAT WASHER ZP 8
22 M10X40HEADSCREW M10 X 40 ALLEN HEAD SCREW HT ZP 1
23 M10X30 M10 X 30 HEX HEAD BOLT HT ZP 1
24 M10X25HEADSCREW M10 X 25 ALLEN HEAD SCREW HT ZP 1
25 M10HHNUT M10 HEX HALF NUT HT ZP 1
26 M10FWASHER M10 FLAT WASHER ZP 1
27 M8X25HEADSCREW M8 X 25 ALLEN HEAD SCREW HT ZP 2
28 M8NNUT M8 NYLOC NUT HT ZP 2
29 M8HHNUT M8 HEX HALF NUT HT ZP 2
30 M8FWASHER M8 FLAT WASHER ZP 2
31 ROLLPIN4 ROLL PIN DIAMETER 4 5
