Pinto BT-POM 1212 - Revision 5
Assembly Drawings & Parts
R-M2012 - Foam Marker 20LPM
Pos Part No Description
2
2A
2B
4
4
5
5
6
7
8
8A
9
9A
9B
11
12
RHAA116
RHCB-DPDT
RHCB-BKR25
RHTLS-6SL
RH4-TLA-5T-LID
RH10437-A
RHACE001
RHAA485\
RHVR34
RHAA427
RHMKR-RK415
RH60001
RH654831
RH621102
RH627076
RHEL-14
RHAA122
RHSHU9439506
RHSHU9439107
RHTP-3814
RHEL-3814
RHA-14
RH3350-0082A
Cab control
Toggle switch
Breaker, 25 amp
Tank lid, 6’
Tank lid, 6’ (Willmar)
Tank, 14 Gallon
Tank, 19 Gallon (Willmar)
Speed control
Tubing, 3/4'”
Air pump assembly
Air pump repair kit
Air fi lter
Intake reed valve
Exhaust reed valve
Brush set
¼ mpt x ¼” elbow barb
Liquid pump assy FL2100-
647
Diaphragm kit, Santoprene
Bypass valve kit, 60 psi,
Viton
Elbow barb
Elbow barb
Straight barb
Strainer, 80 mesh
Note: Includes the complete air pump assembly with hose
barbs and electrical plug-in installed. Common parts for the
air pump are as follows.
Note: Complete assembly with hose barbs and electrical plug
in. Common parts for the liquid pump are as follows.
Pos Part No Description
12
13
14
14A
14B
16
17
17A
18
RH3800-0047
RH3351-0020
RH1700-0090
RHSE-12PP
RHAA429
RHAB144-1-3
RHF-34PP
RHEL-1234PP
RHMKR-CHK14
RHAA358
RH4916-34
RH4193A-PP2-
100SS
RH18999R
RHGF60
RHF0005
RHAA366SS
80 Mesh screen
Strainer bowl
Strainer gasket
Street El
Directo-Valve assembly
Valve Repair Kit, 144-1-3
Plug
Elbow barb
Check valve, air
Check valve assembly
Orifi ce plate, #34
Check strainer, 100 mesh
Seat gasket
Pressure gauge
Cabinet lid (RHS)
Stainless steel tank skid
Note: This valve includes the fi ttings that are attatched
directly to it. For a valve only, order a 144-1-3.
PARTS NOT SHOWN
To Next Page
