Pinto BT-POM 1212 - Revision 5
Section 7 GBNEWE-18/21C - Centre Section 16-21m
1 GBBG020409 CENTRAL FRAME 1
2 GBBG024889 CYLINDER 70MM 2
3 GBBG024892 SEAL KIT 2
4 GB570500008Z NIPPLE 1/4” 0.8MM 4
5 GB600500001 COPPER WASHER 4
6 GB900324090Z CYLINDER BOLT 2
7 GB905400024 NYLOC NUT M24 2
8 GB905200024Z LOCK NUT M24 2
9 GB500300025V EXT STROKE LIMITER 2
10 GB920100034Z BALL JOINT M24 2
11 GB500100005 PIN 4
12 GB500400004Z WASHER 8
13 GB900710025Z SCREW M10
X25 8
14 GB500100068Z DAMPENER SHAFT 2
15 GB500400016Z DAMPENER RETAINER 2
16 GB911634920 BELLEVILLE WASHER M16 32
17 GB905400016 NYLOC NUT M16 2
18 GB905500054 DOME NUT M24 2
19 GB919800020 GREASE NIPPLE 2
20 GB201800415V CENTRE RAIL SUPPORT 1
21 GB500500002Z U-BOLT 2
22 GB905300010 NUT 4
23 GB950130030 BOOM END CAP 2
24 N/A
25 GB9550500500 5 HOLE TUBE 1
Pos Part No Description Qty Pos Part No Description Qty
Parts in italics are non-stock items and may need to be ordered.
NOTE
26 N/A
27 N/A
28 N/A
29 GB201800065V SAFETY STICKER PLATE 1
30A GB500500004V U-BOLT M6 3
30B GB999900100 SPRAY TUBE MOUNTING KIT 3
31 GB905300006 NUT M6 6
32 GB201800418V BOOM TUBE BRACKET 3
33 A425130 BOOM TUBE 2 PIECE CLAMP 3
34 GB904506040X SET SCREW M6
X45 6
