7.41
Pinto BT-POM 1212 - Revision 5
Section 7 GBNEWE-18/21C - Centre Section 16-21m
Pos Part No Description Qty Pos Part No Description Qty
1 GB382000700V SELF LEVELING FRAME 1
2 GB993802001V TIE ROD FIXED 1
3 GB993802002Z TIE ROD ADJUSTABLE 1
4 GB950300002 Silent Block 4
5 GB500400019Z WASHER 2
6 GB905400024 NYLOC NUT M24 4
7 GB993806003V WEAR PAD PLATE 2
8 GB911225915 WASHER 6
9 GB905400012 NUT 4
10 GB900324110Z TIE ROD BOLT 2
11 GB950200020 WEAR DISK NYLON 32
12 GB950170050 END CAP 2
13 GB702540001V TILT CYLINDER 1
14 GB996000196 SEAL KIT 1
15 GB570500006Z NIPPLE 1/4”BSP 0.6mm 2
16 GB600500001 COPPER WASHER 2
17 GB500700073 SELF LEVEL WIRE CABLE 2
18 GB919700120 CABLE TIE 2
19 GB905300012 NUT 2
20 GB900314060Z BOLT 2
21 GB907014028Z BUSH 4
22 GB905300014 NUT 2
23 GB919800060Z LOCKING COLLAR 2
24 GB919800060Z COLLAR SCREW 2
25 N/A
Parts in italics are non-stock items and may need to be ordered.
NOTE
26 N/A
27 N/A
28 N/A
29 GB702540010V LOCKING CYLINDER 1
30 GB996000178 SEAL KIT 1
31 GB570500011Z NIPPLE 1/4”BSP 1.5mm 2
32 GB600500001 COPPER WASHER 2
33 GB905200022Z NUT M22 2
34 GB501100007 END PIECE 2
35 GB900110035Z BOLT 4
36 GB907010021Z WASHER 4
37 GB905300010 NUT 4
38 N/A
39 N/A
40 N/A
