7.43
Pinto BT-POM 1212 - Revision 5
Section 7
Pos Part No Description Qty Pos Part No Description Qty
1 GB201600420V FIRST ARM RH 1
2 GB201600421V FIRST ARM LH 1
3 GB201600450V SECOND ARM RH 1
4 GB201600451V SECOND ARM LH 1
5 GB201600470V BREAKAWAY ARM RH 1
6 GB201600471V BREAKAWAY ARM LH 1
7 GB500100055V PIN 2
8 GB900110025Z SCREW 2
9 GB907200010Z WASHER 2
10 GB919800020 GREASE NIPPLE 4
11 GB702545001V CYLINDER 2
12 GB996000176 SEAL KIT 2
13 GB570500006Z NIPPLE 1/4”BSP 0.6
MM 4
14 GB600500001 COPPER WASHER 4
15 GB500100010Z PIN 2
16 GB919800021X CIRCLIP 4
17 GB905200020Z LOCKING NUT 2
18 GB201200060Z CYLINDER ROD BLOCK 2
19 GB500100062 SPACER 2
20 GB900314080Z BOLT 2
21 GB907014028Z BUSH 4
22 GB905400014 NUT NYLOCK 2
23 GB201800050V LINK ROD 2
24 GB500500014Z BOLT 4
25 GB905400016 LOCKING NUT 16
MM 4
26 GB500100065Z SHAFT BOLT 2
27 GB905400024 NYLOC NUT 24MM 2
28 GB907302025Z WASHER 4
29 GB500200049 BUSH 2
30 GB500100111Z BREAKAWAY SHAFT 2
31 GB919900023Z BREAKAWAY SPRING 2
32 GB500400019Z WASHER 2
33 GB905200024Z NUT 24
MM 4
34 GB950130030 BOOM END CAP 2
35 GB900116050Z BOLT 2
36 GB905100016Z NUT 2
37 GB950200001 BOOM STOP 30
MM 2
37 GB950200004 BOOM STOP 20
MM 4
Parts in italics are non-stock items and may need to be ordered.
NOTE
GBNEWE-165-RH or LH 16m Boom Std
38 GB907110040Z WASHER 6
39 GB905400008 NUT 6
40 GB907108024Z WASHER 6
41 GB202100101V BOOM GUIDE BOTTOM 2
42 GB500500003Z U-BOLT SMALL 2
43 GB905400010 NUT 4
44 GB907010021Z WASHER 4
45 GB202100102V BOOM GUIDE TOP 2
46 GB500500001Z U-BOLT LARGE 2
47 GB550300500 SPRAY RAIL 3 HOLES 2
48 GB550200500 SPRAY RAIL 2 HOLES 2
49 GB550500500 SPRAY RAIL 5 HOLES 2
50 N/A
51 N/A
52 N/A
53 N/A
55 GB999900100 BOOM TUBE KIT 18
56 GB201800418V BOOM TUBE BRACKET 18
57 GB500500004Z U-BOLT 18
58 GB905300006 NUT M6 16
59 A425130 BOOM CLAMP 18
60 GB904506040X SCREW M45
X6 36
61 GB905400006X NUT M6 36
62 GB550401500 SPRAY RAIL 4 HOLES 2
63 N/A
64 N/A
65 N/A
66 UP-420 HYD HOSE CLAMP 10
67 GB900106030Z BOLT M6
X45 10
To Next Page
