7.49
Pinto BT-POM 1212 - Revision 5
Section 7 GBNEWE-185GV-RH or LH 18m Boom Gvar
Pos Part No Description Qty Pos Part No Description Qty
49 GB905400016 LOCKING NUT 16
MM
4
50 GB500100065Z SHAFT BOLT 2
51 GB905400024 NYLOC NUT 24
MM
2
52 GB907302025Z WASHER 4
53 GB500200049 BUSH 2
54 GB500100111Z BREAKAWAY SHAFT 2
55 GB919900023Z BREAKAWAY SPRING 2
56 GB950130030 BOOM END CAP 2
57 GB900116050Z BOLT 2
58 GB905100016Z NUT 2
59 GB950200001 BOOM STOP 30
MM
2
59 GB950200004 BOOM STOP 20
MM
4
60 GB907110040Z WASHER 6
61 GB907108024Z WASHER 6
62 GB905400008 NUT 6
63 GB202100101V BOOM GUIDE BOTTOM 2
64 GB500500001Z U-BOLT LARGE 2
65 GB905400010 NUT 4
66 GB202100102V BOOM GUIDE TOP 2
67 GB500500003Z U-BOLT SMALL 2
68 N/A
69 N/A
70 N/A
71 N/A
72 GB999900100 BOOM TUBE KIT 18
73 GB201800418V BOOM TUBE BRACKET 18
74 GB500500004Z U-BOLT 18
75 GB905300006 NUT M6 16
76 A425130 BOOM CLAMP 18
77 GB904506040X SCREW M45
X
6 36
78 GB905400006X NUT M6 36
79 UP-420 HYD HOSE CLAMP 10
80 GB900106030Z BOLT M6
X
45 10
81 N/A
82 N/A
83 N/A
85 GB550400500 SPRAY RAIL 4 HOLES 2
86 GB550400500 SPRAY RAIL 4 HOLES 2
87 GB550300500 SPRAY RAIL 3 HOLES 2
88 GB550500500 SPRAY RAIL 5 HOLES 2
1 GB201800552V G-VAR PIVOT ARM RH 1
2 GB201800553V G-VAR PIVOT ARM LH 1
3 GB201800520V G-VAR INNER ARM RH 1
4 GB201800521V G-VAR INNER ARM LH 1
5 GB201800450V SECOND ARM RH 1
6 GB201800451V SECOND ARM LH 1
7 GB201600470V BREAKAWAY ARM RH 1
8 GB201600471V BREAKAWAY ARM LH 1
9 GB500100055V PIN 2
10 GB907200010Z WASHER 2
11 GB900110025Z SCREW 2
12 GB500400004Z WASHER 8
13 GB900710025Z SCREW M10X25 8
14 GB500100031 ROD FIRST ARM-PIVOT 2
15 GB919800020 GREASE NIPPLE 4
16 GBBG007491 GVAR CYLINDER 2
17 GB996000174 SEAL KIT 2
18 GB570500006Z NIPPLE 1/4”BSP 0.6
MM 8
19 GB600500001 COPPER WASHER 8
20 GB271600046V LEVEL INDICATOR BRKT 2
21 GB271600045V LEVEL INDICATOR ROD 2
22 GB905100010Z LOCKING NUT 4
23 GB907010021Z WASHER 4
24 GB500100023Z GVAR CYLINDER PIN 2
25 GB905200024Z NUT M24 2
26 GB201800540Z CYLINDER EXT M24 2
27 GB500400019Z WASHER 4
28 GB919900040V GVAR CYL SPRING 4
29 GB201800547Z BUSHING EXTENSION 2
30 GB500100043Z GVAR EXTENSION PIN 2
31 GB201800548Z CYLINDER SPACER 2
32 GB201800545Z SPRING PLATE 2
33 GB905300012 NUT 4
34 GB907012025Z WASHER 4
35 GB905300016 NUT 2
36 GB907017030Z WASHER 2
37 GB702545001V CYLINDER 2
38 GB996000176 SEAL KIT 2
39 GB500100010Z PIN 2
40 GB919800021X CIRCLIP 4
41 GB905200020Z LOCKING NUT 2
42 GB201200060Z CYLINDER ROD BLOCK 2
43 GB500100062 SPACER 2
44 GB900314080Z BOLT 2
45 GB907014028Z BUSH 4
46 GB905400014 NUT NYLOCK 2
47 GB201800050V LINK ROD 2
48 GB500500014Z BOLT 4
Parts in italics are non-stock items and may need to be ordered.
NOTE
To Next Page
