7.55
Pinto BT-POM 1212 - Revision 5
Section 7 GBNEWE-245-RH or LH 24m Boom Standard
Pos Part No Description Qty Pos Part No Description Qty
63 GB950200001 BOOM STOPPER 30MM 2
64 GB905400008 SELF-LOCKING NUT 6
65 GB907108024Z WASHER 6
66 GB907110040Z WASHER 6
67 GB022400053V BOOM GUIDE TONGUE 2
68 GB500500003Z U BOLT 2
69 GB500500001Z UBOLT (LONG) 2
70 GB905400010 NUT 4
71 GB907010021Z WASHER 4
72 GB022400054V BOOM GUIDE 2
73 GB500500002Z UBOLT 2
74 UP-420 HYD HOSE CLAMP 16
75 GB900306035Z BOLT 16
76 GB905300006 NUT 16
77 GB550501500 5 HOLE SPRAY TUBE 1
78 GB550601500 6 HOLE SPRAY TUBE 1
79 GB550601500 6 HOLE SPRAY TUBE 1
80 GB550501500 5 HOLE SPRAY TUBE 1
81 GB999900004Z N.A
82 GB500600002Z N.A
83 GB900508022Z N.A
84 GB906000008Z N.A
85 GB999900100 BOOM TUBE SUPPORT KIT 24
86 GB201800418V SUPPORT BRACKET 24
87 GB500500004Z U BOLT 24
88 A425130 TUBE CLAMP 24
89 GB904506040X SCREW 24
90 GB905400006X NUT 24
3 GB022400030V INNER BOOM ARM R/H 1
4 GB022400031V INNER BOOM ARM L/H 1
5 GB022400050V OUTER BOOM ARM R/H 1
6 GB022400051V OUTER BOOM ARM L/H 1
7 GB201600470V BREAKAWAY ARM R/H 1
8 GB201600471V BREAKAWAY ARM L/H 1
9 GB919800020 GREASE NIPPLE 2
10 GB500100055V PIN 2
12 GB900110025Z M10
X 20MM BOLT (ZINC) 8.8 2
13 GB907200010Z 10
MM SPRING WASHER 2
17 GB950200059 N.A
18 GB900106016Z N.A
19 GB907106018Z N.A
30 GB600500001 COPPER WASHER 4
40 GB500200029Z SPACER 4
41 GB022800037V LINK ARM ROD 4
42 GB022800036V LINK ROD 2
43 GBBG004138 CYLINDER OUTER FOLD 2
44 GB996000177 SEAL KIT CYLINDER 2
45 GB570500007Z NIPPLE 1/4” 0.7MM ORIFICE 4
46 GB500100014Z PIN FOR CYLINDER 2
47 GB919800030 CIRCLIP 4
48 GB920100053Z BALL JOINT M27 2
49 GB500516095Z BOLT 4
50 GB907017030Z WASHER 12
51 GB905400016 LOCK NUT 16MM 6
52 GB500100081 BUSHING 2
53 GB500100080Z SHAFT ROD 2
54 GB905400024 SELF-LOCKING NUT M24 6
55 GB907302025Z WASHER 4
56 GB900124050Z SCREW 2
57 GB905200024Z NUT M24 8
58 GB500200049 BUSH 2
59 GB500100111Z SHAFT BREAKAWAY 2
60 GB919900023Z SPRING BREAKAWAY 2
61 GB500400019Z WASHER 2
62 GB950130030 BOOM END CAP 18
63 GB950200004 BOOM STOPPER 20MM 4
Parts in italics are non-stock items and may need to be ordered.
NOTE
To Next Page
