Pinto BT-POM 1212 - Revision 5
Section 7 GBNEWE-245GV-RH or LH 24m Boom Gvar
Pos Part No Description Qty Pos Part No Description Qty
44 GB996000177 SEAL KIT CYLINDER 2
45 GB570500007Z NIPPLE 1/4” 0.7MM ORIFICE 4
46 GB500100014Z PIN FOR CYLINDER 2
47 GB919800030 CIRCLIP 4
48 GB920100053Z BALL JOINT M27 2
49 GB500516095Z BOLT 4
50 GB907017030Z WASHER 12
51 GB905400016 LOCK NUT 16MM 6
52 GB500100081 BUSHING 2
53 GB500100080Z SHAFT ROD 2
54 GB905400024 SELF-LOCKING NUT M24 6
55 GB907302025Z WASHER 4
56 GB900124050Z SCREW 2
57 GB905200024Z NUT M24 8
58 GB500200049 BUSH 2
59 GB500100111Z SHAFT BREAKAWAY 2
60 GB919900023Z SPRING BREAKAWAY 2
61 GB500400019Z WASHER 2
62 GB950130030 BOOM END CAP 18
63 GB950200004 BOOM STOPPER 20MM 4
63 GB950200001 BOOM STOPPER 30MM 2
64 GB905400008 SELF-LOCKING NUT 6
65 GB907108024Z WASHER 6
66 GB907110040Z WASHER 6
67 GB022400053V BOOM GUIDE TONGUE 2
68 GB500500003Z U BOLT 2
69 GB500500001Z U BOLT (LONG) 2
70 GB905400010 NUT 4
1 GBBG026447 G-VAR PIVOT ARM R/H V2 1
2 GBBG026449 G-VAR PIVOT ARM L/H V2 1
3 GBBG026378 G-VAR INNER ARM R/H V2 1
4 GBBG026379 G-VAR INNER ARM L/H V2 1
5 GB022400050V OUTER BOOM ARM R/H 1
6 GB022400051V OUTER BOOM ARM L/H 1
7 GBBG020414 BREAKAWAY ARM R/H 1
8 GBBG020415 BREAKAWAY ARM L/H 1
9 GB919800020 GREASE NIPPLE 2
10 GB500100055V PIN 2
12 GB900110025Z M10
X 20MM BOLT (ZINC) 2
13 GB907200010Z 10
MM SPRING WASHER 2
14 GBBG025153 G-VAR BOTTOM PIN V2 2
15 GB500400008Z COUNTERSUNK WASHER 4
16 GB900710025Z SCREW M10X25 10
17 GB950200059 CABLE RETAINER 4
18 GB900106016Z M6
X 16MM BOLT (ZINC) 8.8 8
19 GB907106018Z M6
X 18MM WASHER (ZINC) 8
21 GB919900043V G-VAR RAM SPRING (LARGE) 4
22 GB905400020 M24 (FINE) NYLOC NUT (ZINC) 2
23 GB022400209V SPRING RETAINER 2
24 GB500100125 PIN 300X 95L 2
26 GB022400210 RUBBER PAD 2
27 GB022400208Z CLUTCH 2
28 GBBG000022 HYDRAULIC RAM 2
29 GB996000418 SEAL KIT 2
30 GB600500001 COPPER WASHER 4
31 GB570500011Z NIPPLE 1/4 BSP 1.2 ORIFICE 2
32 GB271600045V BOOM LEVEL INDICATOR 2
33 GB905100010Z LOCKING NUT 4
34 GB907010021Z M10 WASHER (ZINC) 4
35 GB271600046V INDICATOR LOCKING PLATE 2
36 GB905220024Z M24 NUT (ZINC) 2
37 GB920100034Z M24 BALL JOINT 2
38 GB500400004Z COUNTERSUNK WASHER 4
39 GB500100086 PIN 2
40 GB500200029Z SPACER 4
41 GB022800037V LINK ARM ROD 4
42 GB022800036V LINK ROD 2
43 GBBG004138 CYLINDER OUTER FOLD 2
Parts in italics are non-stock items and may need to be ordered.
NOTE
To Next Page
