Pinto BT-POM 1212 - Revision 5
Section 2
Manual Control Valves - 2000 Litre
Chem-E-Flush Nozzle Valve
Chem-E-Flush Drum Rinse Valve
Chem-E-Flush Transfer Valve
Directional Suction Valve -
located above the suction fi lter in front
of the main tank on the left hand side
- used for sourcing liquid from the Main
tank or Flush tank.
Chem-E-fl ush (Option) Valves
Fresh Water/Hand Rinse Tap -
located at the left front corner of the
main tank.
Bottom Fill Inlet -
located at front of the main tank on the
left hand side.
Tank Agitator & Probe Valves -
located at the front of the main tank on
the left hand side.
Pressure Flow Valve -
located at the front of the main tank on
the left hand side.
