1.3
Pinto BT-POM 1212 - Revision 5
Section 1
General Description &
Specifi cations
The new 2000 & 3000 litre Pinto trailed
sprayers feature a new height adjustable
hitch design and new “wide-rail” chassis
for superior strength and ride. The Pinto
provides affordable, practical choices to
meet a wide range of crop and pasture
applications to ensure efficient, high
speed, accurate, safe, easy, economic
and timely spraying operations even in
diffi cult terrain.
Choose from 16, 18, 21 & 24 metre fully
hydraulic booms, 18 metre manual folding
suspension boom with hydraulic height
adjustment, single or tandem axle wheel
confi guration and many other options.
Electric sprayer controls, integrated
suction probe, 200 litre fl ushing tank, 30
litre fresh water tank and four point fi ltration
provide easy, safe spraying operation.
The Pinto is fi tted with a big 160
litre/min, A & R positive displacement
diaphragm pump for trouble free, low
maintenance operation. PTO drive is
standard.
General Specifi cations
3000 litre Pinto.
Tank
2000 or 3000 litre polyethylene tank with
quick release hinged lid, fi lling strainer,
top/bottom fi ll, hydraulic venturi agitation,
antivortex suction, tank drain outlet and
calibrated tank.
Chassis
Strong , solid fabricated, wide rail chassis
designed for maximum durability.
Standard with single wheels (solid axle)
12.4 x 24 for 2000 litre, & 14.9 x 28 for
3000 litre.
Options include tandem Simplicity-style
axle c/with independent suspension
and 15” Landcruiser-style wheels. Other
options are 18.4 x 30 single wheels and
mudguards.
Boom
• 18 metre (60’) manual fold
Torquemaster boom - with
parallellogram suspension & hydraulic
height adjustment. Non-drip, quick
release nozzles. Corrosion and
chemical resistant poly bond fi nish.
• 16, 18, 21 & 24 metre (50, 60’, 70’ &
80’) fully hydraulic boom - stronger
and designed for smoother, more
accurate spraying and long life.
Airbag boom suspension system
protects the boom and improves
the boom ride.
Hydraulic boom lift with easy to
read, 1500mm calibrated height
adjustment.
Adjustable boom breakaways with
90° self returning boom ends.
Boom hydraulically side-folds and
locks for transport. Self levelling
standard.
Protected nozzle bodies and skids
standard. Chemical and corrosion resistant
fi nish. Optional fenceline nozzle & hydraulic
wing lift with in-cab controls available.
Pump
A & R positive displacement, oil bath
diaphragm pump with chemical resistant
diaphragms. AR160 -160 l/min, maximum
pressure 2000 kPa (284 psi). Series 4 PTO
drive standard.
Filtration
4 point fi ltration:
• Basket Strainer 18 mesh
• Suction Filter 50 mesh
• Pressure Line Filter 80 mesh
• Nozzle Filters 100 mesh
Foam Marker (Optional)
1 Salvarani double-sided foam marker
with 20 litre foam tank or RHS 2012
double sided, or
2 RHS 2012 double sided, 20 l/min
foam marker with 55 litre tank and
electrical in cab switch control.
Controller
Electric controls with 3 section boom
control & pressure adjustment standard.
Optional: Automatic sprayer controller for
greater accuracy and chemical savings.
Chemical Handling
Integrated suction probe transports
chemical directly into the tank without
putting chemical through the pump.
Optional: Chem-e-fl ush 60 litre.
Flushing & Safety
200 litre polyethylene tank with threaded
lid giving large capacity sprayer fl ushing
facility. 30 litre fresh water tank.
Dimensions (Boom folded)
Model L x W x H
2000 6.5m x 2.9m x 3.0m
3000 6.5m x 2.9m x 3.0m
Approx Weight 1550 kg (2000 litre Dry)
1820 kg (3000 litre Dry)
Machine specifi cations are sub ject to change without prior
notifi cation.
2000 litre Pinto.
