5.12
Pinto BT-POM 1212 - Revision 5
Lubrication & MaintenanceBooms
3 Check springs (B) shown in fi gure 5
above; replace them if yielded.
4 Periodically check all hydraulic hoses
and fi ttings for wear and replace if
necessary.
End of Season
Maintenance
1 Before storage clean all equipment
thoroughly.
2 If necessary protect sprayer plumbing
components with antifreeze fl uid to
avoid damage in severe temperatures.
Periodical Maintenance
1 Clean nozzles
Remove nozzle clogging using
compressed air or a soft bristle brush.
Never use sharpened or pointed
tools.
Always use protective gloves when cleaning
nozzles.
CAUTION
2 Check springs(A) and (B) shown in
fi gure 4 above; replace then if
fl attened or damaged.
