17
30 Battery equalization
Battery equalization
Battery equalization disable (default)
If “Flooded” or “User-Defined” is selected in program 05, this program
can be set up.
31
Battery equalization
voltage
Default setting: 29.2V
Setting range is from 25.0V to 30.0V. Increment of each click is 0.1V.
33
Battery equalized time
60min (default)
Setting range is from 5min to
900min. Increment of each click is
5min.
34
Battery equalized
timeout
120min (default)
Setting range is from 5min to 900
min. Increment of each click is 5
min.
35
Equalization interval
30days (default)
Setting range is from 0 to 90 days.
Increment of each click is 1 day
36
Equalization activated
immediately
Enable
Disable (default)
If equalization function is enabled in program 30, this program can be set
up. If “Enable” is selected in this program, it’s to activate battery
equalization immediately and LCD main page will shows “
”. If
“Disable” is selected, it will cancel equalization function until next
activated equalization time arrives based on program 35 setting. At this
time, “ ” will not be shown in LCD main page.
Display Setting
The LCD display information will be switched in turns by pressing “UP” or “DOWN” key. The selectable
information is switched as below order: input voltage, input frequency, PV voltage, charging current, charging
power (only for MPPT models), battery voltage, output voltage, output frequency, load percentage, load in
Watt, load in VA, load in Watt, DC discharging current, main CPU Version and second CPU Version.
Selectable information LCD display
Input voltage/Output voltage
(Default Display Screen)
Input Voltage=230V, output voltage=230V
