12
3 SAFETY SIGN LOCATIONS
The types of safety signs and locations on the equipment are shown in the illustration below. Good safety requires
that you familiarize yourself with the various Safety Signs, the type of warning and the area, or particular function
related to that area, that requires your SAFETY AWARENESS.
•ThinkSAFETY!WorkSAFELY!
201001
Excessive towing speed can cause serious
injury or death.
Do NOT exceed 65 mph (105 km/h)
M
201151
WARNING
1. Make certain that the wheel lug nuts and axle
mounting hardware are tight.
105
km/h
2. Check pressure and
overall condition of
tires.
Ensure tow vehicle has towing capacity for the weight of this
machine.
Do not tow the machine unless the draw bar is bolted in
place and the safety bolt on the end of the draw bar is
securely fastened.
Close engine fuel cuto (where applicable) before towing
mixer to prevent leakage into the engine crankcase.
Use 2 people to lift and position hitch (pintle and ball) on
and o tow vehicle.
Securely attach hitch to towing vehicle - pintle or ball type
coupler (ball type shown).
Be certain ball clamp captures ball and lever or handwheel
is fully clamped. Ensure use of safety pin through latch or
handwheel (for ball type coupler).
Safety chain attachment (see illustration) chains must cross
under the draw bar and be positioned to prevent the draw
bar from dropping to the ground in the event of a hitch
failure.
Connect lighting plug/electric brake
plug (where applicable).
Make certain that the wheel lug nuts
and axle mounting hardware are tight.
Check pressure and overall
condition of tires.
Test brakes
(if applicable).
N
201150
NOTICE
CAUTION
Use 2 people to lift and po-
sition hitch on and o tow
vehicle.
201155
P
N
P
M
REMEMBER - If Safety Signs have been dam-
aged, removed, become illegible or parts
replaced without safety signs, new signs must
be applied. New safety signs are available from
your authorized dealer.
