CHECKING BOLT TORQUE
The tables shown below give correct torque values for various bolts and capscrews. Tighten all bolts to the torques
specied in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide.
Replace hardware with the same strength bolt.
7.2 BOLT TORQUE
Torque gures indicated above are valid for non-greased or non-oiled threads and heads unless otherwise specied.
Therefore, do not grease or oil bolts or capscrews unless otherwise specied in this manual. When using locking ele-
ments, increase torque values by 5%.
Bolt
Dia.
"A"
Bolt
Dia.
"A"
Bolt Torque*
Bolt Torque*
SAE 2
Nm Ft-Lbs
SAE 5
Nm Ft-Lbs
SAE 8
Nm Ft-Lbs
8.8
Nm Ft-Lbs
10.9
Nm Ft-Lbs
Imperial Torque Specications
Metric Torque Specications
1/4
5/16
3/8
7/16
1/2
9/16
5/8
3/4
7/8
1
8
13
27
41
61
95
128
225
230
345
6
10
20
30
45
60
95
165
170
225
12
25
45
72
110
155
215
390
570
850
9
19
33
53
80
115
160
290
420
630
17
36
63
100
155
220
305
540
880
1320
12
27
45
75
115
165
220
400
650
970
M4
M5
M6
M8
M10
M12
M14
M16
M20
M24
3
6
10
25
50
90
140
225
435
750
2.2
4
7
18
37
66
103
166
321
553
4.5
9
15
35
70
125
200
310
610
1050
3.3
7
11
26
52
92
148
229
450
774
WHEEL LUG NUT TORQUE:
Use the tightening pattern shown below, to ensure the even
tightening of the lug nuts on each wheel.
* Torque value for bolts and capscrews are identied by their head markings.
10.9
SAE-2
SAE-5 SAE-8
Bolt Bolt Torque
Dia Nm Ft-Lbs
1/2" 136 100
9/16" 203 150
