Crown Com-Tech CT-210 - Typical Frequency Response; Typical Damping Factor; Typical Output Impedance

Page 43
Com-Tech Power Amplifiers
Reference Manual
10 100 1 K 10 K 100 K
FREQUENCY (Hz)
+2
+1
0
–1
–2
–3
–4
dB
–5
–6
–7
4 ohm
8 ohm
1 watt
504.0
126.8
31.8
MILLIOHMS
8.0
2.0
6 dB
20 100 1 K 10 K 20 K
400
200
100
0
600
800
1000
1200
1400
FREQUENCY (Hz)
8 ohm
10 100 1 K 10 K 100 K
FREQUENCY (Hz)
Fig. 6.9 Typical Frequency Response
Fig. 6.10 Typical Damping Factor
Fig. 6.11 Typical Output Impedance
