Page 42
Macro-Tech 5002VZ Power Amplifier
Reference Manual
8.2 Level Control Shaft Lock
A security accessory, the shaft lock can be used to se-
cure your amplifier’s level controls in situations where
the front panel controls are subject to tampering. One is
Fig. 8.4 Installing a Level Control Shaft Lock
needed for each channel. They can be ordered through
the Crown Service/Parts Department. For more informa-
tion, contact the Crown Service Department.
P.I.P.-PA
permits the unique capability of adding one mic/
line input directly to each channel of an amplifier. With phan-
tom power for microphones, this mic/line input may be re-
motely switched from mic to line priorities.
P.I.P.-RPA
A phantom-power mixer that has four balanced
mic or line inputs with voiceover capability and adjustable
“duck” level, 84 dB of attenuation. A 10-volt DC source for
remote control capability is provided. The P.I.P.-EXT (Part
M44731-4), available from service, allows the P.I.P.-RPA and
other PIP cards to be “extended” outside the amplifier for
easy set up.
P.I.P.-RPAT
has the same features as the P.I.P.-RPA but in-
cludes four input transformers.
P.I.P.-XOV is a versatile, economical mono 12- or 18-dB/
octave crossover/filter which offers bi-amping and tri-amping
capability.
For more information on these or other
PIPs
under development, contact your local dealer or Crown’s Technical
Support Group.
