Crown Macro-Tech 602, Macro-Tech 1202 - Typical Crosstalk for the Macro-Tech 602

Macro-Tech
®
602/1202/2402 Power Amplifiers
Page 35
Reference Manual
+45˚
0˚
–45˚
100 1 K 10 K 20 K
FREQUENCY (Hz)
100 1 K 10 K 20 K
FREQUENCY (Hz)
dB
TEF
®
Measurement
Fig. 6.11 Typical Crosstalk for the Macro-Tech 602
TEF
®
Measurement
–51
–57
–63
–69
–75
–81
Fig. 6.10 Typical Phase Response
