700 Series Installation Instructions TES1589 Iss.B Page 12
OPERATING SYSTEM
After switch on, the computer will perform the start up sequence and the Windows® XP
desktop will be displayed as shown below.
The 700 Series is controlled by means of ‘icons’ on the desktop. Each application is
accessed by double clicking on the individual icon for that application. The desktop will only
show the programs associated with the particular model you have purchased and may not
display all the programs shown below.
SHUT DOWN
Double click to shut the system down. This will take a short period of time
during which the ‘Windows is shutting down’ message will be displayed. When
the computer has shut down it is safe to turn the power off.
PETROL EXHAUST ANALYSIS (UK Models only)
Double click to launch the Petrol Exhaust Analysis program. For details of how
to use this program, connections and operation of the gas analyser, please
refer to the on-screen Operators Manuals.
DIESEL EXHAUST SMOKEMETER (UK only)
Double click to launch the Diesel Smokemeter program. For details of how to
use this program, connections and operation of the Smokemeter, please refer
to the on-screen Operators Manuals.
EXHAUST EMISSIONS ANALYSIS (Non UK only)
Double click to Launch a combined Petrol and Diesel control application.
Please refer to the on-screen Software operating instructions for further
details.
