Vector Sensor Reference Manual 120
Weight < 1000 g (< 2.2 lb) - no cables
Environmental Specifications
Item Specification
Storage Temperature -40°C to 85°C
Operating Temperature -30°C to 70°C
Humidity 95% Non-condensing
Table A-2 Vector Antenna Array Specifications
Operational Specifications
Item Specification
Frequency 1.575 GHz
GPS gain 28 dB
Input Voltage Range 5 to 15 VDC
Mechanical Characteristics
Item Specification
Enclosure Two CDA-RTK antennas mounted on a powder-
coated aluminum bracket with two PVC 1-14-UNS-
2B threaded mounts
Antenna Connectors TNC socket
Mounting Thread 1-14-UNS-2B
Length 64.8 cm (25.5”)
Width 6.74 cm (2.655”)
Height 13.8 cm (5.435”)
Weight < 1.5 kg (< 3.3 lb) - no cable, un-mounted
Environmental Specifications
Item Specification
Storage Temperature -40°C to 85°C
Operating Temperature -30°C to 70°C
Humidity 95% Non-condensing
Table A-3 MBL-3 Specifications
Operational Specifications
Item Specification
-3 dB Bandwidth 283.5 to 325.0 kHz
Input Voltage Range 5 to 15 VDC
Input Current 25 to 35 mA
Mechanical Characteristics
Item Specification
Enclosure PVC plastic
Mounting Thread 1-14-UNS-2B
Antenna Connector TNC socket
Length 128 mm (5.06”)
Width 128 mm (5.06”)
Height 84 mm (3.33”)
Weight 450 g (1.0 lb) - no cable, un-mounted
