Chapter 6. SNMP Option
113
November 2001
Branch Leaf Set Parameter
0. AUTO
1. ON
0. LCD LIGHT
2. OFF
9. MISCELLANEOUS
1. RESET TO DEFAULT (W) Press [ENTER]
Send ASCII 13
0. DISPLAY ALARM See Text 5 10. ALARM BUFFER
1. CLEAR ALARM (W) Press [ENTER] 13
11. LED Status
See Text 6
Text 1:
Data Port Type code:
0 1 2 3 4 5 6 7
Reserved RS-232 ET10 X.21 G.703 V.35 RS-530 No Insert
Text 2:
Data Port Speed code: Unit :Kbps
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
N56 NC 56 112 168 224 280 336 392 448 504 560 616 672 728 784 840 896
N64 NC 64 128 192 256 320 384 448 512 576 640 704 768 832 896 960 1024
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
N56 952 1008 1064 1120 1176 1232 1288 1344 1400 1456 1512 1568 1624 1680 1736 2048
N64 1088 1152 1216 1280 1344 1408 1472 1536 1600 1664 1728 1792 1856 1920 1984 2048
Text 3:
Bert Result transfer format:
Text 1 (9) Text 2 (10) Text 3 (11) Text 4 (12) Text 5 (13) Text 6 (14) Text 7 (15) Text 8 (16)
Bit Err Byte 5 Byte 4 Byte 3 Byte 2 Byte 1 Byte 0 X X
Bit Err Rate 0
0 e - 0 0 X
Bit Err is 48 bits , have to transfer to ASCII for display
Bit Err Rate just an ASCII text string
