Chapter 2. Installation
19
November 2001
2.1 General
This chapter provides detailed instructions for mechanical
installation of the ETU-01A. Following the completion of
installation, please refer to Chapter 3 for operating information.
2.2 Site Preparation
Install the ETU-01A within reach of an easily accessible
grounded AC outlet. The outlet should be capable of furnishing 90
~ 250 VAC (18VDC to 72VDC for DC model unit). Allow at
least 10 cm (4 inch) clearance at the rear of the ETU-01A for
signal lines and interface cables.
2.3 Mechanical Assembly
The ETU-01A is designed for tabletop or bench installation,
and is delivered completely assembled. No provision has been
made for bolting the ETU-01A to a tabletop. An optional 19”
rack mount adapter is available.
2.4 Electrical Installation
2.4.1 Power connection
AC power is supplied to the ETU-01A through a standard
3-prong plug. (Refer to Figure 2-1) The ETU-01A should always
be grounded through the protective earth lead of the power cable.
