CTC Union FRM220-CH01 User Manual

FRM220 Chassis Quick Installation Guide
13
Panels
Figure. Front Panel
Figure. Rear Panels
LED Indicators and Console port
LED Indications:
- PWR 1: LED on/off Power 1 is on / Power 1 is off
- PWR 2: LED on/off Power 2 is on / Power 2 is off
Console slot select switch:
- Slot 1: console port for slot 1 (upper) line card configuration
- Slot 2: console port for slot 2 (lower) line card configuration
DC + DC
Power
Type
AC + AC
Power
Type
AC + DC
Power
Type
One DC
Power
Type
One AC
Power
Type
Slot 1
Slot 2
Console Port
Power LED
Indicators
Console Port
Select Switch
