EN
EN•13
TECHNICAL SPECIFICATIONS
Charger model D250S DUAL SMARTPASS
Model number
D250S Dual, 1044 SMARTPASS, 1058
Max input voltage
22V 22V
Charging voltage
14.4V at 25°C, temperature
compensated
–
Charging current
20A 80A
Back current drain
<1Ah/month <1Ah/month
Ripple*
<4%
–
Ambient tempe-
rature
-20°C to +50°C, output power is reduced automatically at high
temperatures
Charger type
5-step fully automatic charging
–
Battery types
All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity
40–300Ah 28–800Ah
Dimensions
192 x 110 x 65mm (L x W x H)
Insulation class
IP65 (splash and dust proof)
Weight
0.73kg 0.74kg
MPPT**
Yes
–
*) The quality of the charging voltage and charging current are very important. High current
ripple heats the battery and ages the positive electrode. High voltage ripple can damage other
equipment connected to batteries. The battery chargers from CTEK produce very high-quality
voltage and current with low ripple
**) MPPT (Maximum Power Point Tracking) finds the best combination of supply current and
voltage to maximize the power output. This is especially important for Photovoltaic (Solar) Panels
and trailer campers with wiring constraints.
CABLE DIMENSIONS
Recommended minimum cable dimensions in mm²
MIN CABLE DIMENSIONS
UNIT CABLE 0.5m 1m 2m 5m 10m
+IN
4mm
2
4mm
2
4mm
2
6mm
2
10mm
2
+OUT
4mm
2
6mm
2
10mm
2
Lead to ground
1.5mm
2
1.5mm
2
1.5mm
2
1.5mm
2
1.5mm
2
Connection Unit*
4mm
2
6mm
2
10mm
2
10mm
2
10mm
2
+IN
10mm
2
16mm
2
16mm
2
25mm
2
25mm
2
+OUT
10mm
2
16mm
2
16mm
2
*Use included connectors if possible. Consider above recommendation if the units are mounted at different locations.
D250S/D250S DUAL
SMARTPASS
20015686F D250S Dual + SmartPass, Manual, Print file 001.indd 13 2011-12-20 11:19:39
