Hardware Rev – The revision level of the radio module.
MSID – Mobile Station Identification (MSID) a second phone number assigned to the module
Current Status Panel
Current Temp – The temperature currently being sensed by the radio module. Values are in Centigrade.
Activation Status – Indicates whether or not the router has been successfully activated on the serving network.
Network Stability – Indicates whether or not the current network connection is of adequate quality to perform an OTA
activation.
1xRTT Status Panel
ECIO – A figure of merit (EC/IO) describing how well the router can hear (forward link) the serving network when all other
traffic and noise on the same channel is considered. Lower numbers indicate a better quality connection. A strong (small)
RSSI does not necessarily equate to a low EC/IO value.
Channel – The specific CDMA channel that the router is currently using to communicate with the serving network.
EVDO Status Panel – Same as the 1xRTT Status Panel only for the EV-DO bearer.
