LED Indicator
The LED Indicator is a power indicator lamp that illuminates when the
power switch is in the ON position.
Network Connectors
The Network Connectors are used to connect an On-Board NetLink and
other Network Terminals when multiple On-Board networks are required.
Refer to the On-Board NetLink Installation, Operation, and
Maintenance manual CTI-CRYOGENICS P/N 8040390 for more
information.
Address Switch
The Address Switch allows you to select the network address of the
Network Terminal that is connected to the On-Board NetLink.
AUX RS-232 Port
The AUX RS-232 port allows you to connect a PC that is running OCC for
Windows to control the On-Board network. The port supports baud rates
of 2400, 9600, and 19200.
Host RS-232 Port
The Host RS-232 port allows you to connect a host computer to the
Network Terminal to address any pump on the network. The port supports
baud rates of 2400, 9600, 19200, and 38400.
Pumps 00 - 09 Port
The Pumps 00 - 09 Port is the connector to be used to connect the first ten
On-Board Pumps to the Network Terminal as shown in Figure 1-5.
Pumps 10 - 19 Port
The Pumps 10 - 19 Port is the connector to be used to connect ten or more
On-Board Pumps to the Network Terminal as shown in Figure 1-5.
