CTI-CRYOGENICS On-Board Network Terminal User Manual

Network Terminal Installation, Operation, and Maintenance Instructions
P/N 8040375G001 1-3
C
HELIX TECHNOLOGY CORPORATION
-
TI CR
Y
OG
E
N
IC
S
Specifications
Refer to Table 1-1 and Figures 1-2 and 1-3 for the specifications and
dimensions of the half and right hand panel Network Terminal
configurations.
Table 1-1: Network Terminal General Specifications
Parameter Value
Weight 11 lbs. (5.5Kg)
Electrical Input 90/125 VAC 50/60 Hz
180/250 VAC 50/60 Hz
1/4 amp maximum
Ambient Temperature
50
º
F - 100
º
F (10
º
C - 38
º
C)
Communication Interface Host, Service, Auxiliary: RS-232, 9 pin
D connector
Communication Interface
Baud Rates
Host: 2400, 9600, 19200, and 38400
Service: 2400, 9600, and 19200
Auxiliary: 2400, 9600, and 19200
Software Interface Standard On-Board Protocol using pump
ID number. Refer to Appendix B for
more information.

CTI-CRYOGENICS On-Board Network Terminal Specifications

General

Brand	CTI-CRYOGENICS
Model	On-Board Network Terminal
Category	Touch terminals
Language	English
