Network Terminal Installation, Operation, and Service
v P/N 8040375G001
C
HELIX TECHNOLOGY CORPORATION
-
TI CR
Y
OG
E
N
IC
S
Table of Contents (continued)
Establishing Roughing Maps and Password Protection . . . . . . . . . . . . . . . . . . . . . 4-4
Full Rough Coordination Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Turning On the Full Rough Coordination Feature . . . . . . . . . . . . . . . . . . . . . . . 4-5
Power Fail Coordination Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Turning ON the Power Fail Coordination Feature . . . . . . . . . . . . . . . . . . . . . . 4-6
Regeneration Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Setting up Regeneration Groups with the Network Terminal . . . . . . . . . . . . . . 4-7
Starting a Group Regeneration From the Network Terminal . . . . . . . . . . . . . . 4-8
The RS-232 Communication Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Setting the RS-232 Port Baud Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Section 5 - Maintenance
Memory Backup Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Symptoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Battery Voltage Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Memory Backup Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Section 6 - Troubleshooting
If You Have Problems Starting A Group FastRegen . . . . . . . . . . . . . . . . . . . . . . . . 6-1
If You Cannot Communicate With A Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Network Terminal Failure Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Appendix A - Customer Support Information
Appendix B - Network Terminal RS-232 Interface Protocol Format
