Instruction Booklet

7ENGLISH

KHEOS PLUS

1.1 Spare parts

All Kheos Plus spare parts are sold by CTR S.R.L. and can be requested from our points of sale.

Spare parts must be installed by your local dealer’s specialized technicians.

1.2 List of functions

• Recovery: allows the unit to recover both the refrigerant and part of the oil mixed in it, automatically separating and storing

them. The polluted oil is recovered in an external graduated container. After regeneration through the filters, the refrigerant is

stored in a dedicated cylinder. Quantification is performed automatically by the system’s scale.

• Vacuum: the A/C system can be brought to the maximum vacuum level within the preset time and kept in this condition. This

makes it possible to completely evacuate moisture and check vacuum seal for possible leaks.

• Recharge to vehicle:

the regenerated refrigerant can be recycled (after adding new oil if needed) using the methods indicated

by the operator. You can also add the desired quantity of new refrigerant fluid, new oil and UV tracer

• Recharge cylinder: this function is used to fill the internal cylinder and is controlled by an electronic process.

• Automatic cycle: performs the sequence of all the operations required to restore the system to the correct levels of refrigerant

and oil without operator intervention.

Do not use the unit for purposes other than those for which it was designed. When scrapping the machine, you

must comply with current regulations in force locally (bear in mind that the unit contains refrigerant fluids; use

the services of specialized firms).

The unit is supplied with the type of refrigerant indicated in the CE label. Do not refrigerants other than the one

indicated.

The Nordik unit is designed to perform the operations of recovery, vacuum and charge of R134a refrigerant con-

tained in automotive air conditioning systems.

The Nordik unit must not be used to transfer fluids and/or recharge other liquids. Do not fluids other than R134a,

in particular use with flammable liquids is prohibited.

In case of improper use of the station with resulting contamination of the R134s refrigerant and/or of the vacuum

pump oil (e.g. recovery of gas other than R134a, vacuum on circuits containing oils other than the vacuum pump

oil), switch the unit off immediately and contact our technical service department.

Before using the unit, operators must be suitably trained and assisted by technical staff trained by our com-

pany.

Operator: person trained to use the machine (trained directly/indirectly by CTR staff)

Specialized technician: person trained and authorized by CTR to perform technical procedures.
