Instruction Booklet KHEOS PLUS
8 ENGLISH
EN
2. Technical characteristics
The technical specifications shown below refer to the specific models.
Description Unit of measure Nordik
Max absorbed power W 900
Net weight Kg 60
Overall dimensions (HxWXD) cm 104X48X58
Weight (fully charged) kg 75
Vacuum pump flow rate l/min 100
Final vacuum mbar 0.1
System recovery capacity g/min 400
Refrigerant cylinder capacity l 12
Power supply voltage V 220/240
Power supply frequency Hz 50
Max absorbed current A 4
Vehicle coupling diameter (LP – Low pressure) mm 11
Vehicle coupling diameter (HP – High pressure) mm 16
Max operating temperature °C 50
Min operating temperature °C 5
Maximum pneumatic circuit pressure bar 16
For the connection voltage value, instructions are provided on the label on the unit.
The sound pressure value measured is less than 70 dBA therefore the operator does not need to take any particular protection
measure even in case of continuous use (ISO 3746). Nonetheless, the employer is responsible for evaluating the level of noise the
workers are exposed to in accordance with workplace hygiene and safety regulations currently in force.
3. Safety precautions
We recommend you read through every section of this use and maintenance manual carefully before procee-
ding and to make yourself familiar with the unit’s controls.
In case of need, contact only our Technical Service Department (in particular for components repair and repla-
cement).
Do not perform any repair operations. Repair operations performed by inexperienced staff may affect the safety
level of the unit.
Do not place any objects on the unit; the unit must not be used as a support surface or means of transport.
Connection hoses (A/C system) and feed hoses should be positioned in a way that will not cause hindrance and
prevent them from being damaged.
For refrigerant recovery do not use (pressurized) containers that are unfit for the purpose, in terms of material
type and pressure level.
