Cub Cadet 1515 Pars Manual

-12-
PEDAL ASSEMBLY
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 647-0031 Control Assembly, Brake 1
2 647-0049 Control Assembly, Hydro 1
3 710-0604A Screw, Self-tapping, 5/16-18, 0.625 4
4 710-0650 Screw, Self-tapping, 5/16-18, 0.875 1
5 710-1260A Screw, 5/16-18, 0.750 3
6 711-0736 Adjustment Ferrule 1/4-20 x 1.0 2
7 711-1363 Pin, 3/8-16, 3/8 x 2.43 Lg 1
8 712-0431 Nut, Flange Lock, 3/8-16 2
9 712-3004A Nut, Flange Lock, 5/16-18, Gr5 2
10 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 6
11 714-0111 Pin, Cotter, 3/32, 1.0 2
12 719-0584 Pedal, Control 1
13 732-0335 Spring, Compression, .405 x 1.17 1
14 732-0955 Spring, Extension, .50 OD x 1.41 Lg 1
15 732-0963 Spring, Extension, .50 Dia x 6.37 Lg 1
16 735-3049 Pad, Brake, Control 1
17 736-0133 Washer, Flat, .411 x 1.25 x .100 1
18 736-0142 Washer, Flat, .281 x .50 x .063 2
19 736-0187 Washer, Flat .64 ID x 1.24 x .06 2
20 736-0204 Washer, Flat, .344 ID x .62 OD 2
21 736-3004 Washer, Flat, .406 ID x .875 OD x .105 1
22 736-3008 Washer, Flat, .344 x .750 x .120 1
23 738-0155 Shoulder, Screw .437 x 1.62 Lg 1
24 738-0507B Screw, Shoulder, .500 Dia x .434 1
25 741-0225 Bearing, Hex Flange 2
26 741-3065B Bearing, Hex Flange, .628 ID, Split 2
27 747-1137 Rod, Control, Cruise 1
28 747-1138 Rod, Control, Brake Lock 1
29 748-0413 Latch, Cruise 1
30 748-0415B Spacer, .385 ID x .635 OD x 1.54 1
31 783-0653F Bracket, Support, Stearing 1
32 783-0663C Bracket, Lockout, Hydro 1
33 783-1469 Pedal, Brake 1

Cub Cadet 1515 Specifications

General

Cutting Height	1.5-4 inches
Deck Material	Steel
Transmission	Hydrostatic
Number of Blades	2
Fuel Tank Capacity	1.5 gallons
Speed Range	0-5.5 mph
Wheel Size	Front: 15x6 inches, Rear: 20x8 inches
