Cub Cadet 1515 Pars Manual

-1-
DESCRIPTION PAGE
Axle, Front ....................................................... 5, 6
Battery ............................................................. 15, 16
Brake Pedal ..................................................... 11, 12
Bulkhead .......................................................... 17, 18
Mower Deck, 38-inch ........................................ 21, 22
Mower Deck, 42-inch ........................................ 23, 24
Dash Panel ...................................................... 15, 16
Drive System ................................................... 3, 4
Electrical Sysytem ........................................... 27, 28
Engine
Air Filter ........................................................
Blower Housing ............................................
Breather ........................................................
Carburetor ....................................................
Controls ........................................................
Crankcase ....................................................
Crankshaft ....................................................
Cylinder Head ...............................................
Electrical .......................................................
Exhaust..........................................................
Fuel System ..................................................
Oil Pan ..........................................................
Starter ...........................................................
Valves ...........................................................
41
37
33, 34
39, 40
38
29, 30
29, 30
33, 34
35, 36
41
39, 40
31, 32
35, 36
33, 34
Engine Mounting .............................................. 14
Fender ............................................................. 9
Frame .............................................................. 7, 8
Fuel Tank ......................................................... 9
Grille ................................................................ 17, 18
Hood ................................................................ 17, 18
Deck Lift Handle/Linkage ................................. 10
Muffler .............................................................. 14
PTO Clutch ...................................................... 19, 20
Seat ................................................................. 13
Side Panels ..................................................... 17, 18
Steering ........................................................... 5, 6
Transmission, Hydrostatic ............................... 25, 26
Wheels, Front & Rear ...................................... 2
DESCRIPTION PAGE
MODELS 1515 & 1517
TABLE OF CONTENTS
NOTE, For painted parts, please refer
to the list of color codes below. Please
add the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part,
numbered 700-xxxx, is painted Cub
Yellow, the part number to order would
be 700-xxxx-0498.
Cub Yellow: 0498
Cub Beige: 0499
Powder Black: 0637

Cub Cadet 1515 Specifications

General

Cutting Height	1.5-4 inches
Deck Material	Steel
Transmission	Hydrostatic
Number of Blades	2
Fuel Tank Capacity	1.5 gallons
Speed Range	0-5.5 mph
Wheel Size	Front: 15x6 inches, Rear: 20x8 inches
