Cub Cadet 1515 Pars Manual

-26-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 HG-70721 Main Housing, Assembly, Black 1
2 HG-70720 Side Housing, Assembly, Black 1
3 HG-70724 Center Section, Assembly 1
4 HG-51048 Swashplate, Trunnion Machined 1
5 HG-70331 Block - Assembly 1
6 HG-50928 Sealant 10.5
7 HG-51190 Hex Flange Screw 1/4-20 x 1.25 14
9 HG-51062 Shaft, Input 1
10 HG-2000022 Ring - Retaining 1
11 HG-50951 Spacer 1
12 HG-50329 Ring - Retaining 3
13 HG-51161 Seal, Lip .67 x 1.58 x .276 1
14 HG-50315 Ball Bearing 17mm x 40mm x 12mm 1
16 HG-51064 Hex Flange Head Screw 5/16-24 x 0.75 1
17 HG-51140 Lip Seal 18 x 32 x 7 1
18 HG-51119 Arm, Control 1
19 HG-50551 Bearing, 30x52x13 Thrust 2
23 HG-51084 Check Plug Assembly, .027, Washer 2
24 HG-50966 Shaft, Motor 1
27 HG-51130 Gear - Pinnion, 13t 1
28 HG-51129 10t / 48t Gear 1
29 HG-51043 Gear, 10t Jackshaft 1
30 HG-51044 60t Bull Gear 1
31 HG-51088 Sleeve Bearing .75 x 1.750 x .625 2
32 HG-51517 Sleeve Bearing 1.00 x 1.575 x .625 2
33 HG-44875 Washer, 3/4 ID x 1-1/2 OD x .13 2
34 HG-51518 Lip Seal Axle Seal 2
35 HG-51520 Shaft, Black, Axle 1.00 x 11.99 Flange 1
36 HG-51521 Shaft, Black, Axle 1.00 x 17.59 Flange 1
37 HG-44096 Miter Gear (Splined) 2
38 HG-44097 Miter Gear 15t (0.5 ID) 2
39 HG-50146 Shaft 1
40 HG-44871 Ring, Spiral Retaining 2
41 HG-51083 Pin, Jackshaft 1
42 HG-51100 Magnet, Ring 1
43 HG-51136 Spring, Bypass 1
44 HG-50016 Hydro Mounting Screw 3/8-24 x 2.5 Lg 2
45 HG-51132 Filter 1
46 HG-51133 Base, Filter 1
47 HG-51091 Actuator, Bypass 1
48 HG-51098 Rod, Bypass Actuator 1
49 HG-51135 Arm, Bypass 1
50 HG-51116 Retaining Ring 0.250 External 1
51 HG-51081 Seal, Lip .741 x .250 x .250 Tc 1
52 HG-44371 Flat Washer, 5/8 ID x 1.0 OD x .05 1
53 HG-44145 Retaining Ring 1
54 HG-51071 Bearing, Center Block 1
55 HG-2003014 Spring - Helical Compression 1
56 HG-2003017 Washer 1
57 737-3121 20W-50 Oil (Gal) 78.8
58 HG-44092 Brake Yoke 1
59 HG-51072 Rotor, Brake 1
60 HG-44132 Brake Puck 2
61 HG-44134 Puck Plate 1
62 HG-44127 Brake Actuating Pin 2
63 HG-51146 Bolt, 1/4-20 x 2 w/patch, Special Flange 2
65 HG-23711 Spacer 1
66 HG-51345 Spring, Brake Arm Bias 1
67 HG-44138 Square Head Bolt 5/16-24- Ribbed 1
68 HG-44094 Arm, Brake 1
69 HG-44142 Slotted Hex Nut 5/16-24 1
70 HG-44101 Cotter Pin 3/32 x 3/4 1
71 HG-50919 Compression Spring Brake Anti-drag 1
72 HG-50132 Washer, Ht .5 ID x 1 OD x .032 3
73 HG-44130 Flat - Washer 11/32 ID x 7/8 OD 2
74 HG-44761 Oil Seal .625 x 1.0 x.25 1
83 HG-9004800-
2506
Pin, Standard Headless 2
84 HG-51143 Fitting, 5/16 Sae 5/32 Tube 1
85 HG-51147 Hose, Expansion Tank 1
87 HG-51251 Cap, Vent 1
88 HG-50653 Bolt, Self Tapping 10-32 x 1/2 1
94 HG-44147 Ball Bearing .62 ID x 1.38 x .44 1
95 HG-50837 Socket Head Screw, 5/16-24 x 1-1/2 1
96 HG-51200 Spacer, Locating 1
97 HG-50870 Screw 1
98 HG-51120 Arm, Return 1
99 HG-51097 Puck, Adjusting 1
100 HG-51122 Washer, .325 OD x 1.60 ID x .150 1
101 HG-51131 Spring, Extension 1
102 HG-51123 Spacer .560 OD x .260 ID x .870 1
103 HG-51223 Bracket, Torque 1
107 HG-51134 Deflector 1
108 HG-51069 Washer, Shaft .71 ID x 1.15 OD x .030 1
109 HG-9005110-
5600
Plug, SAE #6 1
110 HG-50868 Torx Head Screw, 5/16-18 1
111 HG-51144 O-ring .07 x .301 ID 1
113 HG-51179 Bracket,support Expansion Tank 1
114 HG-51184 Spring Guide 1
116 HG-51196 Silicon Sponge 1
120 HG-70725 Center Section - Filter - Bypass Ass’y1
121 HG-70466 Filter Assembly 1
122 HG-70722 Seal - O-ring Kit 1
128 HG-70503 Kit, Expansion Tank 1
129 HG-51252 Cap, Expansion Tank Shipping 1
135 HG-70723 Block, Assembly 7 Piston 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
HYDROSTATIC TRANSMISSION
