-28-
ELECTRICAL SYSTEM
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 629-0469A Harness Assembly, Headlight 1
2 629-0889 Harness Assembly, Kohler OHV Alternator 1
3 629-1105 Harness Assembly, Kohler, 1
4 629-1106 Harness Assembly, Safety, Reverse 1
5 710-0227 Screw, Ab, #8-18, 0.500 2
6 710-0599 Screw, Self-tapping, 1/4-20, 0.500 2
7 712-3006 Nut, Hex, 1/4-20, Gr5 2
8 725-1303 Switch, Outer Seat Spring 1
9 725-1426 Solenoid, 12V, 100amp 1
10 725-1439 Switch, Inner Seat Spring 1
11 725-1657A Switch, Snap Mount 1
12 725-1741 Switch, Key, 4-Position 1
13 725-1976 Indicator, Monitor, Hour Meter 1
14 725-2054 Key, Switch, Plastic 2
15 725-3233 Switch, Electric PTO, Yellow Knob 1
16 726-0278 Plate, Insulator Boss 1
17 726-0279 Plate, Insulator 2
18 736-0222 Washer, Lock, Ext 1/4 2
19 736-0329 Washer, Lock, 1/4, Regular Duty 2
