Cub Cadet 1515 Pars Manual

-16-
DASH PANEL
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0136 Screw, 1/4-20, 1.75, Gr5 1
2 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
3 710-0604A Screw, 5/16-18, 0.625 8
4 710-0895 Screw, 1/4-15, 0.750 1
5 710-1238 Screw, 5/16-18, .875, Gr5 4
6 710-3217 Screw, Machine, #8-32, 0.375, Trus Phillips 1
7 712-0142 Nut, 8-32 1
8 712-0271 Nut, Hex, 1/4-20, Sems 2
9 712-0397 Nut, Wing, 1/4-20 w/ Bell Washer 2
10 712-3004A Nut, Flange Lock, 5/16-18, Gr5 4
11 731-2615 Dash 1
12 731-2620 Lever, Dash, Cruise 1
13 731-2621 Lever, Dash, Brake 1
14 731-3161 Knob, Throttle Control 1
15 731-3232 Roller, Latch, Hood 1
16 736-3078 Washer, Flat, .349 x 1.00 x .063 6
17 747-1323A Rod, .250 Dia x 4.25 Lg. 1
18 747-2130 Rod, Support, Side Panel RH 1
19 747-2131 Rod, Support, Side Panel LH 1
20 749-04000 Tube, Dash, Support 1
21 783-0462 Bracket, PTO Switch Retainer 1
22 783-1447 Bracket, Support, Battery 1
23 783-1448 Bracket, Support, Hood Latch 1
24 783-1449 Bracket, Battery, Hold Down 1
25 783-1499 Bracket, Rod, Dash 1
26 746-1149 Control, Choke, 23 Lg. 1
27 736-0222 Washer, External Lock, 1/4 2
28 725-1426 Solenoid, 12V, 100 Amp 1
29 725-1706 Battery, 270 CCA, Wet 1
30 712-3087 Nut, Wing, 1/4-20 1
31 738-1132 Screw, Shoulder, 1/4-20, .25 x .15 1
32 710-0751 Screw, 1/4-20, .620, Gr5 1
33 710-0192 Screw, #10-24 X .375 2
34 714-0104 Internal Cotter Pin, .072 x 1.13 1
35 710-0837 Screw, Oval Countersunk, #10-16 X .625 1
36 741-0501 Bearing, Steering Column, .634 ID x 1.36 1
37 783-04003 Steering Bracket 1
