Cub Cadet 1515 Pars Manual

-18-
HOOD & GRILLE
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0211 Bracket Assembly, Grille LH 1
2 603-0212 Bracket Assembly, Grille RH 1
3 603-0583A Bracket Assembly, Hood 1
4 625-0053 Headlight Assembly, Front 1
725-0963 Miniature Lamp, 12V Socket-type 2
725-1649 Socket
, Lamp, Nylon 1/4-Turn 2
731-3138A Lens 1
731-3295 Leflector, Headlight 1
5 703-05000 Hood 1
6 703-2396 Side Panel, RH 1
7 703-2397 Side Panel, LH 1
8 703-2398 Grille 1
9 703-2465 Link, Hood Upper 6.06 2
10 703-2466A Link, Hood, Rear 2
11 703-2495 Screen, LH Side Panel 1
12 703-2496 Screen, RH Side Panel 1
13 703-2563A Bulkhead, Hood, Upper 1
14 710-0351 Screw, #10-16, 0.500, Pan Phillips 6
15 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
16 712-3027 Nut, Flange Lock, 1/4-20 8
17 712-3087 Nut, Wing, 1/4-20 2
18 722-3021 Tape, Two-sided Adhesive Foam 9
19 723-3061 Seal, Heat Baffle 19
20 726-0139 Nut, Speed, 10z U-type 2
21 728-0117 Rivet, Pop, .125 OD, #42 4
22 732-0334 Spring, Compression, .50 OD x .5 Lg 4
23 732-0855A Spring, Latch, Hood 1
24 736-0175 Washer, Spring, .265 x.562 x.025 8
25 736-0400 Washer, Flat, .194 x .62 OD x .063 2
26 738-3141 Screw, Shoulder, .31x .75, 1/4-20 2
27 748-3055 Bushing, Tapered, .32 ID x .69 OD 4
28 783-1467A Bracket, Mounting, Grille LH 1
29 783-1468A Bracket, Mounting, Grille RH 1
30 731-04009 Plenum, Hood 1
31 710-0436 Hex Screw, #10-16 x 0.625 2
