-20-

POWER TAKE-OFF (PTO) SYSTEM

REF.

NO.

PART

NUMBER DESCRIPTION QTY.

1 683-0450 Plate Assembly, Engagement (Model 1517) 1

2 710-0520 Screw, 3/8-16, 1.5 (Model 1517) 1

3 710-0831 Screw, 3/8-16, 5.5 (Model 1517) 1

4 710-1238 Screw, 5/16-18, .875 2

5 710-3144 Screw, 3/8-16, 2.0 (Model 1517) 1

6 712-0229 Push Nut, 3/8 (Model 1517) 1

7 712-0431 Nut, Flange Lock, 3/8-16 4

8 712-3004A Nut, Flange Lock, 5/16-18 3

9 712-3017 Nut, 3/8-16 (Model 1517) 1

10 714-0470 Cotter Pin, 1/8 x 1.25 (Model 1517) 1

11 732-0384 Spring, Extension .62 x 6.12 (Model 1517) 1

12 732-0991A Belt Guard (Model 1517) 1

13 736-0140 Washer, Flat .385 x .62 x .063 (Model 1517) 1

14 736-3010 Washer, Flat .407 x .812 x .135 (Model 1517) 2

15 738-0372 Shoulder Spacer, .380 1

16 748-0415A Spacer, 3/8 x 1.54 2

17 756-0627B Pulley, Idler, 3.5 (Model 1517) 1

18 756-1208 Pulley, Idler, 4.0 (Model 1517) 1

19 783-0891B Deck Stop 1

20 717-1773 Clutch, Electric PTO, 6” (Model 1515) 1

717-1708 Clutch, Electric PTO (Model 1517) 1

21 736-0277 Washer, Flat, 1.031 x 1.620 x .095 1

22 738-0785 Spacer, Shoulder, 1.38 x .445 x .36 1

23 736-0171 Washer, Lock, 7/16, Regular Duty 1

24 710-3157 Screw, 7/16-20, 3.25, Gr5 1

25 710-3025 Screw, 5/16-18, .625, Gr5 2

26 783-1003 Bracket, Clutch 1

27 754-0644 Belt, V-type (Model 1517) 1
