Cub Cadet 1515 Pars Manual

-22-
38-INCH CUTTING DECK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 16606 Bracket, Hook, Retainer 1
2 618-0676 Spindle Assembly, 38" 2
3 683-0611 Deck Assembly, 38" 1
4 703-1890 Wheel, Deck, 5.0 OD w/ Fitting 2
5 710-0528 Screw, 5/16-18, 1.25, Gr5 1
6 710-0602 Screw, Self-tapping, 5/16-18, 1.000 1
7 710-0604A Screw, 5/16-18, 0.625 6
8 710-0650 Screw, Self-tapping, 5/16-18, 0.875 8
9 710-0751 Screw, 1/4-20, .620, Gr5 3
10 710-0817 Screw, Self-tapping, 5/16-18, 1.250 1
11 710-1315 Screw, Self-tapping, 3/8-16, 1.250 2
12 710-3144 Screw, 3/8-16, 2.00, Gr5 1
13 711-0747 Pin, Guide, .250 Dia x 1.68 Lg 1
14 711-3314 Roller Pin 1/2" x 7.31 Lg 1
15 712-0431 Nut, Flange Lock, 3/8-16 5
16 712-3004A Nut, Flange Lock, 5/16-18, Gr5 1
17 712-3006 Nut, Hex, 1/4-20, Gr5 2
18 712-3010 Nut, Hex, 5/16-18, Gr5 1
19 712-3027 Nut, Flange Lock, 1/4-20 2
20 714-0470 Pin, Cotter, 1/8 x 1.25 2
21 714-3004 Pin, Cotter, 3/32 x 1.25 1
22 717-1553B Adjustment Gear, Deck 1
23 726-0233 Nut, Push, .25 ID x .50 OD 2
24 731-1032B Chute Assembly, Side Discharge 1
25 731-2231B Cover, Belt, Deck 1
26 731-2609A Cover, Belt, Deck, LH 1
27 731-3005 Front Roller 1
28 732-0306 Spring, Compression, .406 x .531 x 1.75 Lg 2
29 732-0556 Spring, Extension .94 x 7.57 1
30 734-0973 Wheel Deck 5.0 x 1.38 2
31 736-0105 Washer, Bell, .375 x .870 x .063 4
32 736-0119 Washer, Lock, 5/16, Regular Duty 1
33 736-0272 Washer, Flat, .510 x 1.00 x .060 2
34 737-3007 Grease, Alvania Ep 2 1
35 738-0372A Spacer, Shoulder, 1.00 x .38 x .38 1
36 738-0373 Shoulder Screw 2
37 738-3056 Shoulder Screw - 1/2 Dia x 2.50 Lg. 2
38 742-3032 Blade, 19.38 Lg, 3-in-1 2
39 747-1116 Rod, Handle, Deck Release .375 Dia 2
40 754-0641 Belt, V-Type 1
41 756-0627B Pulley, Idler, 3.50 Dia. 2
42 756-1229 Pulley, Idler, 4.06 Dia. w/ Flange 1
43 737-3000 Fitting, 3/16 Drive Lube 2
44 710-1889 Bolt, Spindle, 3/4-16, 5.85 2
45 783-1417 Bracket, Idler, Arm 1
46 783-1418 Bracket, Idler 1
47 783-1433 Bracket, Deck, Hanger Adjustment 1
48 756-3106 Pulley 2
49 750-1000 Spacer, .80 x 1.10 x 1.330 2
50 748-3065 Spacer, Spindle, Deck 4
51 618-3129A Spindle Housing Assembly 2
750-3190A Spacer, Bearing, .780 x 1.000 x 1.0425 2
721-3018A Seal, Oil, Single Lip 4
741-3029 Cup, Bearing 4
741-3028 Bearing, Cone 4
719-3118A Housing, Spindle, Deck 2
52 712-3078 Nut, Flange, 3/4-16 2

Cub Cadet 1515 Specifications

General

Cutting Height	1.5-4 inches
Deck Material	Steel
Transmission	Hydrostatic
Number of Blades	2
Fuel Tank Capacity	1.5 gallons
Speed Range	0-5.5 mph
Wheel Size	Front: 15x6 inches, Rear: 20x8 inches
