-24-
42-INCH CUTTING DECK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 16606 Bracket, Hook, Retainer 1
2 618-0677 Spindle Assembly, 42" 2
3 683-0254 Bracket Assembly, Deck, Hanger LH 1
4 683-0607 Deck Assembly, 42" 1
5 703-1890 Wheel, Deck, 5.0 OD w/ Fitting 2
6 710-0136 Screw, 1/4-20, 1.75, Gr5 1
7 710-0520 Screw, 3/8-16, 1.50, Gr5 1
8 710-0528 Screw, 5/16-18, 1.25, Gr5 1
9 710-0751 Screw, 1/4-20, .620, Gr5 3
10 710-1238 Screw, 5/16-18, .875, Gr5 1
11 710-1260A Screw, 5/16-18, .750 12
12 710-3151 Screw, 5/8-18, 4.25, Gr5 1
13 711-3314 Roller Pin, 1/2" x 7.31 Lg 1
14 712-0337 Nut, Hex, 5/8-18, Gr5 1
15 712-0431 Nut, Flange Lock, 3/8-16 5
16 712-3004A Nut, Flange Lock, 5/16-18, Gr5 1
17 712-3006 Nut, Hex, 1/4-20, Gr5 3
18 712-3027 Nut, Flange Lock, 1/4-20 2
19 714-0470 Pin, Cotter, 1/8 x 1.25 2
20 714-3004 Pin, Cotter, 3/32 x 1.25 1
21 716-3020 Snap Ring, Internal 2
22 717-1553B Adjustment Gear, Deck 1
23 726-0233 Nut, Push, .25 ID x .50 OD 2
24 731-1032B Chute Assembly, Side Discharge 1
25 731-2486A Cover, Belt, 42" Deck 2
26 731-3005 Front Roller 1
27 732-0306 Spring, Compression, .406 x .531 x 1.75 Lg 2
28 732-0470A Spring, Extension .530 OD x 4.74 Lg 1
29 734-0973 Wheel Deck 5.0 x 1.38 2
30 736-0105 Washer, Bell, .375 x .870 x .063 4
31 736-0119 Washer, Lock, 5/16, Regular Duty 1
32 736-0158 Washer, Lock, 5/8, Regular Duty 1
33 736-0162 Washer, Flat .64 ID x 1.00 OD x .12 3
34 736-0270 Washer, Bell, .265 x .75 x .062 2
35 736-0272 Washer, Flat, .510 x 1.00 x .060 2
36 736-0343 Washer, Flat, .330 x 1.25 x .120 8
37 738-0373 Shoulder Screw 2
38 738-3056 Shoulder Screw - 1/2 Dia x 2.50 Lg. 2
39 741-0524 Bearing, .625 ID x 1.574 OD x .470 2
40 742-3033 Blade, 21.20 Lg, 3-in-1 2
41 747-1116 Rod, Handle, Deck Release .375 Dia 2
42 748-0331 Spacer, Shoulder .625 Dia x .324 Dia 1
43 750-0932A Spacer, .635 ID x .88 x 1.72 1
44 712-3078 Nut, Flange, 3/4-16 2
45 754-0645 Belt, V-Type 1
46 756-0627B Pulley, Idler, 3.50 Dia. 1
47 756-1202 Pulley, Double, 5.0 x 5.0 1
48 737-3000 Fitting, 3/16 Drive Lube 2
49 710-1889 Bolt, Spindle, 3/4-16, 5.85 2
50 783-1291 Bracket, Idler 1
51 748-3065 Spacer, Spindle, Deck 4
52 756-3106 Pulley 2
53 618-3129A Spindle Housing Assembly 2
750-3190A Spacer, Bearing, .780 x 1.000 x 1.0425 2
721-3018A Seal, Oil, Single Lip 4
741-3029 Cup, Bearing 4
741-3028 Bearing, Cone 4
719-3118A Housing, Spindle, Deck 2
