Cub Cadet 1515 Pars Manual

-6-
STEERING
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0514 Hex Cap Screw, 3/8-16, 1.00, Gr5, Std 2
2 711-1408 Link, Drag, RH 1
3 711-1409A Link, Drag, LH 1
4 712-0237 Nut, Hex Lock, 5/16-24 1
5 712-0240 Nut, Jam, 7/16-20, Gr2 2
6 712-0241 Nut, Hex, 3/8-24, Gr5 2
7 712-0431 Nut, Flange Lock, 3/8-16 4
8 712-0459 Nut, Flange Lock, 7/16-20 1
9 712-3004A Nut, Flange Lock, 5/16-18 2
10 717-1550D Gear, Steering, 11/90 Ratio 1
11 717-1554 Gear, Pinion, Steering 1
12 723-0610 Ball Joint, 7/16-20 2
13 736-0169 Washer, Lock, 3/8 , Regular Duty 2
14 736-0242 Washer, Bell, .340 x .872 x .060 1
15 736-3084 Washer, Flat, .510 x 1.120 x .060 1
16 737-3007 Grease, Alvania Ep 2 1
17 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 2
18 738-1194 Shaft, Steering, .625 OD x 25.00 Lg 1
19 741-0475 Bushing, Plastic, .380 ID 2
20 741-0656 Bearing, Hex Flange, 5/8 1
21 683-0605 Axle Assembly, LH .750 Dia 1
22 683-0606 Axle Assembly, RH .750 Dia 1
23 712-0417A Nut, Hex, Flange, 5/8-18 2
24 714-0162 Pin, Cot, 5/32, 1.25 2
25 719-0583 Axle, Pivot, Cast .750 Dia 1
26 736-0866 Washer, Flat, .755 x 1.92 x.060 2
27 738-1011 Spacer, Shoulder, .500 x 2.230, 3/8-16 2
28 731-3209 Wheel, Steering, Soft Grip, Three Spoke 1
29 731-3210 Cover, Steering Wheel 1

Cub Cadet 1515 Specifications

General

Cutting Height	1.5-4 inches
Deck Material	Steel
Transmission	Hydrostatic
Number of Blades	2
Fuel Tank Capacity	1.5 gallons
Speed Range	0-5.5 mph
Wheel Size	Front: 15x6 inches, Rear: 20x8 inches
