Cub Cadet 1515 Pars Manual

-8-
FRAME
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 683-0304A Frame Assembly, Lower 1
2 683-0612 Bumper Assembly 1
3 710-0604A Screw, Self-tapping, 5/16-18, 0.625 19
4 710-0607 Screw, Self-tapping, 5/16-18, 0.500 1
5 710-0642 Screw, Self-tapping, 1/4-20, 0.750 1
6 710-1238 Screw, 5/16-18, .875, Gr5 2
7 710-1260A Screw, 5/16-18, 0.750 2
8 711-0332 Pin, Clevis, .50 Dia x .78 Lg 2
9 712-0431 Nut, Flange Lock, 3/8-16 2
10 712-0459 Nut, Flange Lock, 7/16-20 2
11 712-3006 Nut, Hex, 1/4-20, Gr5 1
12 714-0145 Pin, Click, .092 x 1.64 Lg 2
13 732-3080A Spring, Compression, 1.28 OD x 3.50 Lg 2
14 736-0222 Washer, Lock, Ext 1/4 2
15 736-0329 Washer, Lock, 1/4, Regular Duty 1
16 736-0331 Washer, Bell, .390 x 1.13 x .062 2
17 736-0407 Washer, Bell .45 x 1.00 x .062 2
18 737-3007 Grease, Alvania Ep 2 1
19 738-0143 Shoulder Screw, 3/8-16 2
20 738-1020 Shoulder Screw .625 x .500, 7/16-20 2
21 783-0726B Bracket, Pivot, Support RH 1
22 783-0727A Bracket, Pivot, Support LH 1
23 783-0728 Bracket, Pivot, Bar 1
24 783-1462 Frame, Upper, Cub 1500 1
25 783-1463 Bracket, Frame, Seat 1
26 722-3022 Foam Tape, .625 x .25 18

Cub Cadet 1515 Specifications

General

Cutting Height	1.5-4 inches
Deck Material	Steel
Transmission	Hydrostatic
Number of Blades	2
Fuel Tank Capacity	1.5 gallons
Speed Range	0-5.5 mph
Wheel Size	Front: 15x6 inches, Rear: 20x8 inches
